794228-1
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
Electrical
| Voltage Rating | 600 V | Contact Resistance | 20mΩ |
| Current Rating (Max) | 9.5 A | Voltage - Supply (Min) | 600VDC/600VAC |
Mechanical
| Depth | 3.81 mm | Pitch | Not Required mm |
| Height | 4.42 mm | Weight | 0.013 |
| Packaging | Bulk | Wire Gauge | 18-22 AWG |
| Termination | Crimp | Contact Type | Power |
| Housing Color | Not Required | Mounting Type | Straight |
| Pin or Socket | Pin | Connector Type | Connector Headers and PCB Receptacles |
| Contact Finish | Pre-Tin | Mounting Style | Snap In |
| Contact Material | Brass | Housing Material | Not Required |
| Length - Overall | 20.2 mm | Termination Style | Quick Connect |
| 1st Contact Gender | Pin (Male) | Number of Contacts | 1 |
| Contact Termination | Crimp | Wire Gauge or Range - AWG | 22-18 |
| Wire Gauge or Range - mm2 | :0.8mm² | Diameter - Outside, Non-Expanded | :2.39mm |
Product Info
| Type | Contact | Gender | PIN |
| Series | Mate-N-Lok II | CAD Drawing | 3D CAD Model |
| Product Type | Receptacle Housings | For Use With/Related Products | :Mini-Universal MATE-N-LOK 2 Connectors |
