点击放大查看
MCP1630RD-LIC2
| Manufacturer | |
| Description | MCP1630 Low Cost Li-ion Battery Charger MCP1630 Low Cost Li-Ion Battery Char BOARD DEMO FOR MCP1630 LI-ION Development Kit, Power Management With Li-Ion Battery Charger Design Board for MCP1630 Battery Management Lo Cost Li-Ion Battery Chrgr Ref MCP1630, BATTARY CHARGER, REF DESIGN Microchip Li-Ion 套件 MCP1630 电池充电器 参考设计 |
| Category |
Business
| MOQ | 5 | Unit Pack | 1 |
| Product Category | Battery Management | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | ||
Electrical
| Core Type | :(Not Available) | Number of Elements | :MCP1630 |
Mechanical
| Weight | 0.25 | ||
Product Info
| Type | Development Kit | Contents | Board, Software |
| Embedded | Yes, MCU, 8-Bit | Features | :Overvoltage/Overtemperature Protection, Over Current Protection in the Event of a Shorted Battery |
| Kit Type | :Power Management - Battery | Technology | Power Management |
| Kit Contents | Li-Ion Battery Charger Design Board for MCP1630 | Main Purpose | Power Management, Battery Charger |
| Manufacturer | :(Not Available) | Card Standard | Development Kit |
| Tool Type Feature | :Evaluation Board | Primary Attributes | 3 Cells- NiMH / NiCd, 1.35A Out, 6V ~ 14 V Input |
| Utilized IC / Part | MCP1630 | Chipset Manufacturer | :Microchip |
| Secondary Attributes | Preconditioning, Cell Temperature and Batt Pack Fault Monitoring | Application Specifics | :Battery Charger |
| MCU Supported Families | :MCP1630, PIC12Fxxx | For Use With/Related Products | :MCP1630 |
