SN75240PWR
| Manufacturer | |
| Description | ESD Suppressor TVS 15KV 8-Pin TSSOP T/R ESD Suppressors Dual USB Port IC DUAL USB PORT TVS 8-TSSOP USB TRANS SUPPRESSOR, SMD, 75240 Dual USB Port Transient Suppressor Logic IC Quad / Unidirectional / TVS TSSOP-8, SN75240, SN75240PWR, Texas Instruments TVS Diode Arrays Dual USB Port |
| Category |
Business
| Other Names | 296-6596-2 | Product Category | ESD Suppressors |
| Standard Package | Tape & Reel | Factory Pack Quantity | 2000 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Part Status | :75240 | Rad Hardened | No |
| ESD Protection | 15@HBM/2@MM | ||
Electrical
| Channels | 4 Channels | Capacitance | 35(Typ) pF |
| Power (Watts) | 60W | Voltage Rating | 6(Min) V |
| Current - Output | :-9A | Current - Leakage | 1uA |
| Number of Outputs | :4 | Voltage - Working | 6V |
| Number of Channels | 4 | Number of Elements | 2 |
| Voltage - Clamping | 7V | Capacitance - Input | 35 |
| Diode Configuration | :TSSOP | Voltage - Breakdown | 7 V |
| Current Rating (Max) | Catalog | Voltage - Input (Min) | :7V |
| Voltage - Supply (Min) | 3.3 V | Power Dissipation (Max) | :60W |
| Current - Reverse Leakage @ Vr | 1 uA | ||
Mechanical
| Depth | 4.4 mm | Width | 4.5(Max) |
| Height | 1.15 mm | Weight | 0.001376 oz |
| Packaging | Reel | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | Surface Mount | Number of Pins | :8 |
| Package / Case | TSSOP-8 | Locking Feature | TVS |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 3 mm |
| Package Quantity | TSSOP | Number of Positions | 8 |
| Shell Size - Insert | 1.05(Max) | Supplier Device Package | 8-TSSOP |
Product Info
| Type | TVS | Series | SN75240 |
| Polarity | Uni-Directional | Software | SLLS266H |
| Base Unit | :75240 | Diode Type | :ESD Protection |
| Technology | Mixed Technology | Applications | USB |
| Configuration | Dual | Number of Circuits | 1 |
| Utilized IC / Part | View | Printed Circuit Board | 8 |
Environmental
| Temperature Range | :Commercial | Temperature - Test | 0 to 70 |
| Operating Temperature | 0 °C | Operating Temperature - Junction | 70C |
