565-200-100
| Manufacturer | |
| Description | CONNECTORS MODULAR Pin & Socket Connectors WIRE SEAL HOLE COVER WATERPROOFING CAP Waterproofing Cap white, 565-200-100, Edac EDAC 565 系列 防水盖, 使用于防水连接器 |
| Category |
Business
| Standard Package | 250 | ||
Compliance
| RoHS | No | Material Flammability Rating | UL 94 V-0 |
Electrical
| Voltage Rating | 250 V | Current Rating (Max) | 3 A |
Mechanical
| Pitch | 2.5 mm | Material | PBT |
| Contact Finish | Tin | Mounting Style | Wire |
| Contact Material | Phosphor Bronze | Housing Material | Polybutylene Terephthalate (PBT) |
| Termination Style | Crimp | Color - Connectors | white |
| Number of Contacts | 2 | Wire Gauge or Range - AWG | 28-22 |
Product Info
| Series | 565 | Features | Waterproof (Mated, IP67) |
| Description | Waterproofing Cap | Accessory Type | Sealing Cap |
| For Use With/Related Products | 防水连接器 | ||
Environmental
| Seal Rating | IP67 | ||
Documents & Media
Similar Parts
565-002-000-311
EDAC
Pin & Socket Connectors 2WAY 3A PLUG (20-22) WATERPROOF HSNG BLK CONN PLUG 2WAY BLACK 22-28AWG CONNECTOR, HOUSING, PLUG, 2POS, 2.5MM
565-002-000-411
EDAC
Pin & Socket Connectors 2WAY 3A RCPT (20-22) WATERPROOF HSNG BLK CONN RECEPT 2WAY BLACK 22-28AWG CONNECTOR, HOUSING, RECEPTACLE, 2POS, 2.5MM
565-005-000-311
EDAC
Pin & Socket Connectors 5P 3A MALE HSNG BLK 1.3-1.7MM INSUL DIA CONN HOUSING 5POS WATERPROOF
565-003-000-311
EDAC
Pin & Socket Connectors 3P 3A MALE HSNG BLK 1.3-1.7MM INSUL DIA CONN HOUSING 3POS WATERPROOF
565-003-000-411
EDAC
Pin & Socket Connectors 3P 3A FEM HSNG BLK 1.3-1.7MM INSUL DIA CONN HOUSING 3POS WATERPROOF
565-005-000-411
EDAC
Pin & Socket Connectors 5P 3A FEM HSNG BLK 1.3-1.7MM INSUL DIA CONN HOUSING 5POS WATERPROOF
565-005-000-310
EDAC Inc
CONN PLUG 5 WAY BLACK 22-28AWG Pin & Socket Connectors 5WAY 3A PLUG (28-22) WATERPROOF HSNG BLK CONNECTOR, HOUSING, PLUG, 5POS, 2.5MM Connector: wire-wire; 565; plug; male; PIN:5; IP67; Locking: lock
565-002-000-310
EDAC Inc
CONN PLUG 2 WAY BLACK 22-28AWG Pin & Socket Connectors 2WAY 3A PLUG (22-28) WATERPROOF HSNG BLK CONNECTOR, HOUSING, PLUG, 2POS, 2.5MM Connector: wire-wire; 565; plug; male; PIN:2; IP67; Locking: lock
565-003-000-410
EDAC Inc
CONN RCPT 3 WAY BLACK 22-28AWG Headers & Wire Housings 3WAY 3A RCPT (22-28) WATERPROOF HSNG BLK Conn Housing RCP 3 POS 2.5mm Crimp ST Cable Mount CONNECTOR, HOUSING, RECEPTACLE, 3POS Connector: wire-wire; 565; plug; female; PIN:3; IP67; Locking: lock
565-005-000-410
EDAC Inc
CONN RCPT 5 WAY BLACK 22-28AWG Pin & Socket Connectors 5WAY 3A RCPT (28-22) WATERPROOF HSNG BLK CONNECTOR, HOUSING, RECEPTACLE, 5POS, 2.5MM Connector: wire-wire; 565; plug; female; PIN:5; IP67; Locking: lock
565-003-000-310
