565-005-000-410
| Manufacturer | |
| Description | CONN RCPT 5 WAY BLACK 22-28AWG Pin & Socket Connectors 5WAY 3A RCPT (28-22) WATERPROOF HSNG BLK CONNECTOR, HOUSING, RECEPTACLE, 5POS, 2.5MM Connector: wire-wire; 565; plug; female; PIN:5; IP67; Locking: lock |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 250 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | UL94V-0 | ||
Electrical
| Voltage - Test | 100V | Connector - Voltage Input | w/o terminals |
Mechanical
| Color | Black | Pitch | :2.5mm |
| Width | 16.6mm | Weight | 0 |
| Packaging | Bulk | Contact Type | Female Socket |
| Body Material | PBT | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle | Fastening Type | Latch Holder |
| Mounting Style | for cable | Number of Rows | 1 |
| Locking Feature | lock | Package Quantity | 25 |
| Connector - Cable | plug | Contact Termination | Crimp |
| Number of Positions | 5 | Material - Insulation | silicone rubber |
Product Info
| Spg | 25 | Note | Contacts Not Provided |
| Gender | :Receptacle | Series | :565 Waterproof |
| Features | Waterproof | Product Type | Receptacle Housings |
| Adapter Series | 565 | Number of Units | 1 |
| For Use With/Related Products | :565 Series Crimp Contacts | ||
Environmental
| Ingress Protection | IP67 | Operating Temperature | -40...105°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
