5650470-5
| Manufacturer | |
| Description | Conn DIN 41612 PIN 96 POS 2.54mm Solder ST Thru-Hole Eurocard Type R CONN DIN PLUG 96POS VERT PCB Plug 96 way pin DIN41612 Eurocard DIN 41612 Connectors PLUG 96P VERT TYPE R Conn DIN 41612 PIN 96 POS 2.54mm Solder ST Thru-Hole Product Highlights:PlugNumber of Positions = 96PCB Mount Angle = VerticalNo PCB Retention FeaturePost Type = Solder PostSearch Keywords:parallel, stacking, co-planar, horizontal, high density, midplane, two piece, IEC 603-2, DIN 41612 DIN 41612 PCB CONNECTOR, PLUG, 96WAY EUROCARDTypeRVerticalPlug,96Position,SolderPost,DINLevelII,Gray CONN DIN ASSY,PIN,EUROCARD,TYPE R,LEAD- |
| Category |
Business
| Product Category | DIN 41612 Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | DIN41612,IEC603-2 |
| Tariff No | 85366930 | Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| Approval Agency | CSA,UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 V ac | Contact Resistance | 15 mΩ, 50 mV |
Mechanical
| Color | Gray | Depth | 11.1 mm |
| Pitch | 2.54 mm | Height | 11.51 mm |
| Weight | 0.009 | Coating | Without |
| Packaging | Bulk | Shell Size | R |
| Termination | Solder | Contact Type | Solder Post |
| Length - Pin | 0.18" | Housing Color | Gray |
| Length - Tail | 4.57 mm | Mounting Type | Through Hole |
| Angle of Throw | Straight | Connector Type | Plug, Male Pins |
| Contact Finish | DIN 41612 Class 2 | Mounting Style | Through Hole |
| Number of Rows | 3 | Contact Material | Copper Alloy |
| Housing Material | Polymer | Length - Overall | 95 mm |
| Primary Material | Eurocard | Termination Rows | a/b/c |
| Make Before Break | No | Pin Hole Diameter | 0.1" |
| Termination Style | Solder Pin | Mating Orientation | Without |
| Number of Contacts | 96 | Contact Termination | :Through Hole Vertical |
| Number of Positions | 96 | Material - Insulation | Polymer Thermoplastic, Glass Filled |
| Mounting Hole Diameter | 0.11" | Termination Post Length | 4.57 [0.180] |
Product Info
| Type | DIN 41612 | Grade | II |
| Style | R | Gender | Male |
| Series | 5650470 | Class Code | C2 |
| Guide Method | Without | Manufacturer | Eurocard |
| Product Type | Plug | Number of Positions Loaded | All |
Environmental
| Level, Class | 2 | Operating Temperature | -55°C ~ 125°C |
