1-215912-4

Business

Product Category	DIN 41612 Connectors	Standard Package	Trays
Factory Pack Quantity	30

RoHS	Lead free / RoHS Compliant	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Size	Standard	Color	Gray
Pitch	2.54 mm	Coating	Without
Packaging	Bulk	Termination	Solder
Contact Size	0.64 [.025] Sq.	Contact Type	Compliant Post
Mounting Type	Through Hole	Connector Type	Receptacle, Female Sockets
Contact Finish	Gold Over Nickel	Number of Rows	3
Board Thickness	2.36 [0.093]	Contact Material	Phosphor Bronze
Housing Material	Polyester	Mounting Feature	With
Make Before Break	No	Termination Style	Solder Pin
Number of Contacts	96	Number of Positions	96
Material - Insulation	Polyester Thermoplastic, Glass Filled	Termination Post Length	13.00 [0.512]

Note	Seating tool required.	Type	DIN 41612
Grade	II	Style	C
Gender	Receptacle	Series	Eurocard
Product Type	Type C Connectors	Bus Connection	FUTUREBUS, MULTIBUS (II), NUBUS, VMEbus, VXIBus
Connection Type	Printed Circuit Board	Tool Type Feature	No
Number of Positions Loaded	All
