RDK-91
| Manufacturer | |
| Description | DESIGN ACCELERATOR KIT REFERENCE DESIGN KIT FOR AN AC-DC ADAPTER PCBs & Breadboards TINYSWITCH III REF. DESIGN KIT KIT DESIGN REF TINYSWITCH-III Development Kit, Power Management With Documentation, Power Supply, Reference Board TINYSWITCH-III, POWER SUPPLY, RDK Switching controller design kit, RDK-91, Power Integrations |
| Category |
Business
| Product | Accessories & Kits | Product Category | PCBs & Breadboards |
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85235290 | ||
Electrical
| Power - Output | 12W | Current - Output | 1A |
| Current - Supply | :1A | Regulator Topology | Flyback |
| Voltage - Input (Min) | 12V | ||
Mechanical
| Weight | 0.421 | Packaging | Box |
| Board Thickness | Bare (Unpopulated) and Fully Populated | ||
Product Info
| Type | :Reference Design Kit | Contents | 2 Boards, Samples |
| Technology | Power Management | Kit Contents | Documentation, Power Supply, Reference Board |
| Main Purpose | AC/DC, Primary Side | Card Standard | Development Kit |
| Outputs and Type | 1, Non-Isolated | Utilized IC / Part | TNY274, TNY275, TNY276, TNY277, TNY278, TNY279, TNY280 |
| MCU Supported Families | :TNY278P | ||
Environmental
| Maximum Temperature Limit | :50°C | ||
Documents & Media
