TNY278GN-TL
| Manufacturer | |
| Description | Off Line Switcher 7-Pin SMD-C T/R AC/DC Switching Converters 21.5W 85-265 VAC 28W/230 VAC IC OFFLINE SWIT OVP OTP HV 8SMD AC/DC Converters 21.5W 85-265 VAC 28W/230 VAC |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | TinySwitch | Other Names | 596-1113-1 |
| Product Category | AC/DC Switching Converters | Standard Package | Tape & Reel |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Output Power | 28 W | Power (Watts) | 28W |
| Voltage Rating | 12 V | Frequency Range | 124kHz ~ 140kHz |
| Current - Output | 445 uA | Current - Supply | 445 uA |
| Duty Cycle (Max) | 65 % | Output Isolation | Isolated |
| Voltage - Supply | 265 VAC | Number of Outputs | 1 |
| Voltage - Breakdown | 700V | Frequency - Switching | 132 kHz |
Mechanical
| Packaging | Reel | Mounting Style | SMD/SMT |
| Package / Case | 7SMD-C | Supplier Device Package | SMD-8C |
Product Info
| Type | Off Line Switcher | Series | TNY278 |
| Manufacturer | Power Integrations | ||
Environmental
| Operating Temperature | -40 to 150 °C | ||
