09695120364
| Manufacturer | |
| Description | D-Sub Mixed Contact Connectors DSUB ML 36W4 CRIMP CONN D SUB MA 36W4 CRIMP CONNECTOR WI D-Sub Mixed Connector 36W4 M D-SubMixedConnector36W4M Harting 32（信号），4（功率/同轴）路 直 混合压接 D-Sub 连接器, 插头 |
| Category |
Business
| Part # Aliases | 0364 09 09-69-512-0364 512 69 | Product Category | D-Sub Mixed Contact Connectors |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Current Rating (Max) | 5A | ||
Mechanical
| Depth | 17.7mm | Width | 15.4mm |
| Length | 66.9mm | Packaging | Bulk |
| Orientation | 直 | Contact Type | Coax or Power and Signal |
| Mounting Type | Straight | Connector Type | Plug for Male Contacts |
| Flange Feature | Housing/Shell (Unthreaded) | Number of Rows | 3 |
| Connector Style | D-Sub, Combo | Housing Material | Steel |
| Size / Dimension | 66.9 x 15.4 x 17.7mm | Number of Contacts | 36 |
| Dielectric Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Number of Positions | 36 (32 + 4 Coax or Power) |
| Shell Material, Finish | Steel, Tin Plated | Shell Size, Connector Layout | 5 (DD, D) - 36W4 |
Product Info
| Note | Contacts Not Provided | Gender | Male |
| Series | * | Features | Grounding Indents |
Environmental
| Operating Temperature | 125°C | ||
