690368172072
| Manufacturer | |
| Description | CONN 2.54MM FEM ANGLED POLAR 20P Wurth Elektronik 6903 Series 2.54, 1.27mm 20 Way 2 Row Straight PCB Socket Through Hole Board to Board Headers & Wire Housings WR-MM CONN 2.54MM FEM ANGLED POLAR 20P Wurth Elektronik 6903 系列 2行 20路 直 1.27 mm, 2.54 mm节距 通孔 印刷电路板插座, 板对板 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 732-1981-5 | Standard Package | 21 |
Compliance
| RoHS | Compliant | Material Flammability Rating | UL 94 V-0 |
Electrical
| Voltage Rating | 100 V ac | Current Rating (Max) | 1.5A |
| Insulation Resistance | 1000 MOhms | ||
Mechanical
| Color | Red | Pitch | 0.100" (2.54mm) |
| Packaging | Tube | Orientation | 直 |
| Row Spacing | 0.059" (1.50mm) | Termination | Solder |
| Contact Type | Female Socket | Mounting Type | Through Hole, Right Angle |
| Connector Type | Receptacle | Contact Finish | Tin |
| Number of Rows | 2 | Contact Material | Phosphor Bronze |
| Housing Material | Polybutylene Terephthalate (PBT) | Termination Rows | 焊接 |
| Termination Style | Through Hole - Kinked Pin | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 20 | Number of Positions | 20 |
Product Info
| Type | Board to Board | Series | 6903 |
| Product Type | Connectors | Application Specifics | Wire-to-Board |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | - 40 C to + 105 C | ||
Documents & Media
Online Document
Online Document
Online Document
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Similar Parts
690157002072
