TPD4E004DRYR
| Manufacturer | |
| Description | ESD Suppressor Diode Arrays ±12KV 6-Pin USON T/R ESD Suppressors 4Ch ESD Prot Array TVS DIODE 6SON TVS Diode Array TPD4E004DRYR, SON 6-Pin ESD Suppressor Diode Arrays �12KV 6-Pin USON T/R ESD PROTECTION ARRAY, 4CH, SON-6 ESD PROTECTION IC, 6V, SON 4-Channel ESD Protection Array for High-Speed Data Interfaces Texas Instruments TVS 二极管阵列, 6针 SON封装 ESD Suppressors / TVS Diodes 4Ch ESD Prot Array |
| Category |
Business
| Other Names | 296-23618-1 | Product Category | ESD Suppressors |
| Standard Package | Cut Tape | Factory Pack Quantity | 5000 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| Tariff No | 85423990 | Part Status | ACTIVE |
| Rad Hardened | No | ESD Protection | ±12@Air Gap/±8@Contact Disc/±15@HBM kV |
Electrical
| Channels | 4 Channels | Capacitance | 2 pF |
| Voltage - Supply | :900mV | Current - Leakage | 0.001uA(Typ) |
| Number of Channels | 4 | Number of Elements | 4 |
| Voltage - Clamping | 14 | Capacitance - Input | 1.6 |
| Diode Configuration | :SON | Voltage - Breakdown | 6 V |
| Current Rating (Max) | Catalog | Power Line Protection | Yes |
| Bidirectional Channels | 4 | Voltage - Supply (Min) | :800mV |
| Current - Reverse Leakage @ Vr | 0.001(Typ) uA | ||
Mechanical
| Depth | 1 mm | Width | 1mm |
| Height | 0.5mm | Length | 1.45mm |
| Weight | 0.000002 | Packaging | Reel |
| Common Pin | 8 | Mounting Type | Surface Mount |
| Connector Type | :Surface Mount | Mounting Style | Surface Mount |
| Number of Pins | :6 | Package / Case | SON |
| Package Cooled | SON | Locking Feature | Diode Arrays |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 1.45 mm |
| Package Quantity | 5000 | LARGE T&R | Size / Dimension | 1.45 x 1 x 0.5mm |
| Number of Positions | 6 | Supplier Device Package | 6-SON (1.45x1) |
Product Info
| Type | Diode Arrays | Series | TPD4E004 |
| Features | :- | Function | :4-Channel ESD Protection Array for High-Speed Data Interface |
| Polarity | Uni-Directional | Software | SLVS729A |
| Diode Type | :ESD Protection | Applications | Ethernet |
| Configuration | Quad | Pattern Number | Y |
| Port Direction | Uni-Directional | Utilized IC / Part | View |
Environmental
| Air Flow - Medium | 12 | Temperature - Test | -40 to 85 |
| Operating Temperature | -40 °C | Operating Temperature - Junction | 85C |
