Other Names296-17580-2Product CategoryLDO Voltage Regulators
Standard PackageTape & ReelFactory Pack Quantity3000
Standard Package NameSOT-23

Compliance

RoHSLead free / RoHS CompliantEU RoHSCompliant
Part StatusACTIVERad HardenedNo

Electrical

PSRR43Noise33
Output1Accuracy±2 %
Output TypeFixedPower - Rated560 W
Regulator TypeLinearVoltage Rating2.7 V
Line Regulation0.05(Typ) %/VLoad Regulation5(Typ) mV
Current - Output0.2 ACurrent - Supply170 uA
Voltage - Supply0.12@200mA VNumber of Outputs1
Regulator TopologyPositive FixedCapacitance @ Vr, FCeramic
Current - Input Bias170 uACurrent Rating (Max)Catalog
Number of Regulators1Voltage - Input (Min)3.3V
Output Voltage Accuracy�2 %Power - Average Forward0.56 W
Power Dissipation (Max)560 mWCurrent - Quiescent (Iq)0.17
DC Voltage - Input (Min)2.7 VCurrent - Quiescent (Max)0.25 mA
Voltage Regulation - Load2 %Current - Input Bias (Max)0.17 mA
Common Mode Transient Immunity (Min)Extended

Mechanical

Width1.75(Max)Height1.15 mm
Length2.9 mmWeight0.000459 oz
PackagingTape and ReelLead StyleGull-wing
Mounting TypeSurface MountMounting StyleSMD/SMT
Package / Case5SOT-23Package CooledSOT-23
Length - Overall3.05(Max)Package QuantitySOT-23
Number of Positions5Shell Size - Insert1.3(Max)
Supplier Device PackageSOT-23-5

Product Info

TypeLDOSeriesTPS73033
FeaturesCurrent Limit|Excellent Line and ...PolarityPositive
SoftwareSBVS054JTopologyLDO
ManufacturerTexas InstrumentsPattern NumberY
Outputs and TypeAdjustable Output Fixed OutputFunctional Diagramfbd_sbvs054j.gif
Utilized IC / PartViewOutput Configuration1.8 2.5 2.8 2.85 3 3.3 4.7
Printed Circuit Board5
