794272-1
| Manufacturer | |
| Description | Connector Accessories Seal Protector 3 POS Silicon Rubber Blue .250" Centerline, 600 V, 19 - 36 A max CONN WIRE SEAL 3POS UMNL BLUE universal mate-n-lok 3 way wire seal Power to the Board SPLASH PROOF SEAL 3P Wire Connector Accessories Seal Protector 3 POS Silicon Rubber Blue Product Highlights:AccessoryUniversal MATE-N-LOK Product LineAccessory Type = Seal ProtectorIn-Line Contact LayoutNumber of Positions = 3Search Keywords:wire to wire, wire to board, Lighting Interconnection, soft shell, pcb connectors, power, discrete wire, crimp, PWRSIGALLP WIRE SEAL, 3WAY Connector,SoftShell;UniversalMATE-N-LOK;3;19;600;SiliconRubber;Blue Seal for wire; 6.35mm; PIN:3; Pin layout:1x3; Gasket: silicone Wire seal, 794272-1, TE Connectivity TE Connectivity MATE-N-LOK系列 蓝色 硅橡胶 电线密封 03P UMNL WIRE SEAL |
| Category |
Business
| Product Category | Power to the Board | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | RoHSCompliant,ELVCompliant |
| Tariff No | 85369010 | ||
Electrical
| Voltage Rating | 600 V | Number of Outputs | 3 |
| Current Rating (Max) | 19 A | Connector - Voltage Input | UniversalMATE-N-LOK |
Mechanical
| Color | Blue | Depth | 7.62 mm |
| Height | 10.16 mm | Weight | 0.075 |
| Wire Gauge | :0.5mm² | Pitch - Post | 6.35mm |
| Shell Plating | :Silicone Rubber | Mounting Style | Press Fit |
| Connector Usage | seal for wire | Housing Material | Silicon Rubber |
| Length - Overall | 20.32 mm | Package Quantity | 500 |
| Primary Material | Interconnect | Termination Style | Quick Connect |
| 1st Contact Gender | Socket (Female) | Color - Connectors | :Blue |
| Number of Contacts | 3 | Number of Positions | 3 |
| Center Contact Finish | 0.25 | Material - Insulation | silicone |
| Contact Layout, Typical | In-Line | Wire Gauge or Range - AWG | 30-16 |
| Wire Gauge or Range - mm2 | :2.0mm² | 1st Connector Mounting Feature | 1x3 |
| Diameter - Outside, Non-Expanded | :3.3mm | ||
Product Info
| Spg | 500 | Type | Seal Protector |
| Series | :Sealed Universal Mate-N-Lok | Features | Splash-Proof |
| CAD Drawing | 3D CAD Model | Manufacturer | MATE-N-LOK |
| Product Type | Accessories | Accessory Type | Seal |
| Adapter Series | Universal MATE-N-LOK | Number of Units | 1 |
| RF Family/Standard | 794272 | For Use With/Related Products | Universal MATE-N-LOK Series |
Environmental
| Ingress Protection | IP56 for 1,52...2,79mm cable, IP57 for 2,79...3,3mm cable | ||
