66505-9

Business

Product Category	Standard Circular Contacts	Standard Package	Bulk
Factory Pack Quantity	1000

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant

Voltage Rating	250 V	Contact Resistance	:15mohm
Current Rating (Max)	1.2 A

Depth	2.16 mm	Pitch	Not Required mm
Length	14.35mm	Weight	0.009
Plating	Gold	Material	Phosphor Bronze
Packaging	Bulk	Wire Gauge	24-28 AWG
Termination	Crimp	Contact Size	20
Contact Type	Signal	Mounting Type	Straight
Pin or Socket	Socket	Connector Type	Connector D-Subminiature
Contact Finish	Gold Over Nickel	Mounting Style	Cable
Contact Material	Phosphor Bronze	Housing Material	Not Required
Length - Overall	14.1 mm	Package Quantity	Loose Piece
Insulation Height	Yes	1st Contact Gender	Pin (Male)
Number of Contacts	Not Required	Contact Termination	Crimp Snap-In
Insulation Diameter	0.76 â 1.02 [0.030 â 0.040]	Plating - Thickness	Flash
Wire Gauge or Range - AWG	:28AWG	Wire Gauge or Range - mm2	0.08 - 0.20 [28-24]
Diameter - Outside, Non-Expanded	:1.02mm

Type	Stamped	Grade	Standard
Gender	SKT	Series	HDP-20 (Crimp Snap)
Product Type	Contact	Number of Ports	1 Port
For Use With/Related Products	:HDP-20 Series Connectors	For Use With/Related Manufacturer	CPC Connectors, AMPLIMITE HDP-20
