206438-2

Business

Tradename	CPC Series 2	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Compliance	No	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Black	Depth	38.1 mm
Height	44.01 mm	Sealed	No
Weight	0.02	Diameter	44.01 mm
Packaging	Bulk	Cable Exit	No
Shell Size	23	Orientation	Keyed
Shell Style	Receptacle	Termination	Crimp
Thread Size	1-3/8 - 18 UNEF-2A	Contact Form	57Signal
Contact Size	20	Contact Type	Crimp
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Receptacle for Female Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Connector Style	Receptacle	Insertion Angle	:23-57
Material - Body	:Thermoplastic	Housing Material	Thermoplastic
Length - Overall	23.47 mm	Primary Material	CircularPlasticConnector
Termination Style	Wire	1st Contact Gender	Socket
Color - Connectors	:Black	Mating Orientation	Keyed
Number of Contacts	57	Panel Cutout Shape	:40.9mm
Contact Tail Length	20D	Insulation Diameter	1.73 [0.068]
Number of Positions	57	Shell Size - Insert	All Plastic
Shell Material, Finish	Thermoplastic	1st Connector Mounting Type	:Cable
2nd Connector Mounting Feature	Reverse	Shell Size - Insert (Convert To)	23-57

Note	Contacts Not Provided	Type	CPC
Gender	RCP	Series	Series 2
Features	ReverseGender	Preloaded	No
Arrangement	23-57	Manufacturer	Series2
Product Type	Connector	RF Family/Standard	206438
Other Specifications	Without	Application Specifics	Commercial
For Use With/Related Products	Socket Contacts
