66103-4

Business

Tradename	Multimate	Product Category	Standard Circular Contacts
Standard Package	Bulk	Factory Pack Quantity	1000

RoHS	Lead free / RoHS Compliant	Standards	RoHSCompliant
Tariff No	85369010

Current - Output	13A	Current Rating (Max)	13 A
Connector - Voltage Input	CPC Series 1, CPC Series 4

Depth	2.92 mm	Pitch	Not Required mm
Weight	0.04	Plating	Gold
Material	Brass	Packaging	Bulk
Wire Type	Discrete	Wire Gauge	20-24 AWG
Termination	Crimp	Contact Size	:16
Contact Type	Signal	Pin Diameter	0.062in.
Mounting Type	Straight	Pin or Socket	Pin
Cable Diameter	1.02...2.03mm	Connector Type	Connector Power
Contact Finish	Gold over Nickel	Mounting Style	Cable
Package / Case	in bulk	Contact Material	Brass
Housing Material	Not Required	Length - Overall	27.48 mm
Material - Frame	StainlessSteel	Package Quantity	1
Connector - Cable	contact	1st Contact Gender	Pin (Male)
Color - Connectors	:Gold	Number of Contacts	1 POS
Contact Tail Length	16	Contact Termination	Crimp
Insulation Diameter	0.040to0.080in.	Plating - Thickness	30µin (0.76µm)
Wire Gauge or Range - AWG	:24AWG	Wire Gauge or Range - mm2	:0.6mm²
Contact Material - Plating	gold plated	Diameter - Outside, Non-Expanded	:2.03mm

Spg	1	Type	Stamped
Grade	Commercial	Gender	PIN
Series	Multimate Type III	CAD Drawing	3D CAD Model
Manufacturer	AMP	Adapter Series	Type III+
Number of Ports	1 Port	Number of Units	1
For Use With/Related Products	:Type III+ Series Connectors
