640252-2
| Manufacturer | |
| Description | Contact SKT Crimp ST Cable Mount Strip MTA, CST, CST-100 II and SL Contacts CONN SOCKET 18-24AWG SL156 TIN Headers & Wire Housings RCPT CONTACT 18-24G Contact SKT Crimp ST Cable Mount Strip Product Highlights:SL-156 ContactsWire Termination Type = CrimpPre-Tin Contact Mating Area Plating MaterialWire Size = 0.9-0.2² [18-24] mm² [AWG]Used For SL-156 HousingsSearch Keywords:.100 Centerline, 2-28 positions, 5 A, 250 VAC, 2-24 positions, 7 A, 600 VAC, Wire-to-Board, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, PWRSIGALLP CONTACT, CRIMP, RECEPTACLE, 24-18AWG CONTACT, CRIMP, SOCKET, 24-18AWG, REEL CONTACT,RECEPTACLE,SL-156,18-24AWG,CRIMP SL-156 RECEPTACLE |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | 7,000 |
| Factory Pack Quantity | 700 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85366910 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
Electrical
| Voltage Rating | 250 V | Contact Resistance | 3 mohm |
| Current Rating (Max) | 4 A | Voltage - Supply (Min) | 250VAC |
Mechanical
| Depth | 3.56 mm | Pitch | Not Required mm |
| Weight | 0.002 | Packaging | Tape & Reel (TR) |
| Wire Gauge | 0.9-0.2² [18-24] | Termination | Crimp |
| Contact Type | Signal | Housing Color | Not Required |
| Mounting Type | Straight | Pin or Socket | Socket |
| Connector Type | Connector Headers and PCB Receptacles | Contact Finish | Pre-Tin |
| Mounting Style | Cable | Insertion Force | High Force |
| Operating Force | High | Contact Material | Brass |
| Housing Material | Not Required | Package Quantity | Strip |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | Not Required | Contact Termination | Crimp |
| Insulation Diameter | 2.79 [0.110] | Contact Finish Thickness | 130µin (3.30µm) |
| Wire Gauge or Range - AWG | :24AWG | ||
Product Info
| Note | Recommended for 1 thru 12 position housings. | Type | Contact |
| Gender | SKT | Series | SL-156 |
| Product Type | SL-156 Contacts | For Use With/Related Products | SL-156 Housings |
Environmental
| Operating Temperature | -55C to 105C | ||
