552443-1
| Manufacturer | |
| Description | Conn IEEE 488 PL 24 POS 2.16mm IDT RA Cable Mount 24Terminal 1Port Tray 2.16 [.085] IDC Connectors 24 CONTACT,CHAMP PLUG SCREW LOCK Headers & Wire Housings PLUG 24P SCREW LOCK 26-28 AWG stranded Conn IEEE 488 PL 24 POS 2.16mm IDT RA Cable Mount 24 Terminal 1 Port Tray Conn IEEE 488 PL 24 POS 2.16mm IDT RA Cable Mount 24 Terminal 1 Port Tray Product Highlights:Connector Classification = IDCProduct Category = ConnectorsConnector24 PositionsPlugSearch Keywords:self-extinguishing housing, integral latching system, 0.8mm, .050, .085 Centerline Miniature Ribbon Connectors (CHAMP), ribbon cable, input/output, discrete wire, AMPHENOL, Centronics |
| Category |
Business
| Lead Time | 98 Days | Other Names | A1530 |
| Subcategory | Connector Interface | Product Category | Connectors |
| Standard Package | Trays | Factory Pack Quantity | 100 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | ||
Mechanical
| Pitch | 2.16 mm | Packaging | Tray |
| Thickness | Thick | Cable Type | 7 Strand |
| Copper Type | E | Shield Type | No |
| Termination | IDC | 2nd Connector | With |
| Housing Color | Yellow | Mounting Type | Cable Mount |
| Connector Type | Plug | Contact Finish | Gold (30) over Nickel (50), Gold Flash over Palladium Nickel over Nickel |
| Flange Feature | Insert, Threaded (4-40) | Number of Rows | 2 |
| Connector Style | PS | Locking Feature | Screwlocks |
| Profile (W x H) | Standard | Package Quantity | Tray |
| Panel Mount Type | Without | Insulation Diameter | 1.14 [.045] Max. |
| Number of Positions | 24 | Contact Finish Thickness | 30µin (0.76µm) |
| Wire Gauge or Range - mm2 | 0.09² [28], 0.10² [27], 0.14² [26] | ||
Product Info
| Type | IEEE 488 | Gender | PL |
| Product Type | Connector | ||
