487223-9
| Manufacturer | |
| Description | Conn Housing RCP 34 POS 2.54mm Crimp ST Cable Mount Flexible Film Connectors 034 HOUSING FFC RCPT 100CL DR FFC & FPC Connectors 34 HSG RCPT 100CL DR Flexible Film Connectors Product Highlights:Housing2.54 mm CenterlineConnector Type = Standard34 PositionsNumber of Rows = DualSearch Keywords:Circuitry-to-Board, cable to board, board to board, FFC, flat flexible cable, flat flex wire, Easy Mating Connector |
| Category |
Business
| Other Names | 4872239 | Standard Pack | 1 |
| Product Category | FFC & FPC Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | Yes |
Electrical
| Voltage Rating | 300V | Voltage - Supply | 300 VAC |
| Resistance - Input | 5000 | Voltage - Clamping | 720 |
| Current Rating (Max) | 2A | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Lock Type | 不带 | Packaging | Bulk |
| Body Color | 黑色 | Cable Type | FFC |
| Polarization | Center | 2nd Connector | Without |
| Mounting Type | Straight | Connector Type | Standard |
| Number of Rows | 2 | Connector Usage | Receptacle |
| Housing Material | Thermoplastic | Mounting Feature | Without |
| Package Quantity | 1 | Panel Mount Type | Without |
| Termination Style | 插座 | FFC, FCB Thickness | 0.05-0.13mm |
| Mating Orientation | With | Number of Contacts | 34 |
| Number of Positions | 34 | Mounting Hole Diameter | 带有 |
| Center Contact Material | 2.54 [0.100] | ||
Product Info
| Note | Use Extraction Tool No. 91093-1 for round wire contacts. | Type | Housing |
| Gender | RCP | Features | Locking Ramp |
| Product Type | Housing | Connection Type | FFC Cable |
Environmental
| Operating Temperature | -65°C ~ 105°C | ||
