350547-7
| Manufacturer | |
| Description | Contact PIN Crimp ST Cable Mount Loose Piece .250" Centerline, 600 V, 19 - 36 A max CONN PIN 14-20AWG GOLD CRIMP Contact,crimp,pin,Mate-n-lok,20-14 awg Pin & Socket Connectors PIN CONTACT 20-14 Contact PIN Crimp ST Cable Mount Loose Piece Product Highlights:ContactUniversal MATE-N-LOKNot CompactPCIContact Type = PinWire Range = 0.50-2.00² [20-14] mm [AWG]Search Keywords:wire to wire, wire to board, Lighting Interconnection, soft shell, pcb connectors, power, discrete wire, crimp, PWRSIGALLP TERMINAL, SOLDERLESS CONTACT,PIN,UNIVERSALMATE-N-LOK,20-14AWG TE Connectivity Universal MATE-N-LOK 系列 公 压接接线端子, 压接, 镀金触点 UMNL PIN 20-14 AUBR L/P |
| Category |
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
Electrical
| Voltage Rating | 600 V | Current Rating (Max) | 19 A |
| Voltage - Supply (Min) | 600VAC | ||
Mechanical
| Depth | 4.31 mm | Pitch | Not Required mm |
| Weight | 0.02 | Packaging | Bulk |
| Wire Gauge | 14-20 AWG | Termination | Crimp |
| Contact Size | :14 | Contact Type | Power |
| Mounting Type | Straight | Pin or Socket | Pin |
| Connector Type | Connector Power | Contact Finish | Gold Over Nickel |
| Mounting Style | Cable | Contact Material | Brass |
| Housing Material | Not Required | Length - Overall | 20.44 mm |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 1 POS | Contact Termination | Crimp |
| Contact Finish Thickness | 30µin (0.76µm) | Wire Gauge or Range - AWG | 20-14 |
Product Info
| Type | Contact | Gender | PIN |
| Series | Universal Mate-N-Lok | CAD Drawing | 3D CAD Model |
| Product Type | Contacts | Number of Ports | 1 Port |
| For Use With/Related Products | :Universal MATE-N-LOK Connectors | ||
