226537-4
| Manufacturer | |
| Description | Contact PIN Crimp ST Cable Mount Barrier Terminal Blocks SUBMIN PIN MULTIMATE Multiple Coaxial Contacts (COAXICON) CONN PIN COAXIAL/SHIELDED 26AWG Multiple Coaxial Contacts (COAXICON) Product Highlights:ContactPinTerminate To Coaxial Cable, Terminate To Shielded WireCable Type = Belden 9221, RD 316, RG 161, RG 174, RG 174DB, RG 179, RG 187, RG 187DB, RG 188, RG 316Wire Range = 0.12-0.15; [26] mm [AWG]Search Keywords:RF, multi position, SUB MIN PIN MULTIMATE |
| Category |
Business
| Product | Barrier Terminal Blocks | Standard Pack | 100 |
| Product Category | Barrier Terminal Blocks | Standard Package | Bulk |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | ||
Electrical
| Impedance | Non-Matched | Connector Impedance | 不匹配 |
Mechanical
| Packaging | Bulk | Cable Type | Belden 9221, RD 316, RG 161, RG 174, RG 174DB, RG 179, RG 187, RG 187DB, RG 188 |
| Wire Gauge | 26 AWG | Termination | Crimp |
| Contact Size | 16 | Contact Type | Power |
| Pin or Socket | Pin | Shell Plating | Gold (50) over Nickel (50) |
| Connector Type | Connector Circular | Contact Finish | Gold Over Nickel |
| Shell Material | Brass per MIL-C-50 | Contact Material | Beryllium Copper |
| Housing Material | 黄铜 | Primary Material | 直式 |
| Termination Style | 插针 | Conductor Material | Beryllium Copper per QQ-C-533 |
| Contact Termination | Crimp | Dielectric Material | TPX |
| Center Contact Finish | 金 | Center Contact Plating | Gold (50) over Copper (100) |
| Center Contact Material | 铍铜合金 | Supplier Device Package | CPC, G Series, M Series, Metrimate |
| Contact Finish Thickness | 50µin (1.27µm) | Contact Material - Mating | Without |
| Wire Gauge or Range - mm2 | 0.12-0.15; [26] | ||
Product Info
| Note | A ferrule is required for each pin and socket.; Extraction Tool No. 305183 | Type | Machined |
| Gender | PIN | Series | COAXICON |
| Manufacturer | AMP | Product Type | Contact |
| Connection Type | Coaxial Cable, Shielded Wire | For Use With/Related Manufacturer | CPC Connectors |
