207018-1
| Manufacturer | |
| Description | Conn Housing RCP 12 POS 5mm ST Metrimate Connectors CONN RECEPT 12 POS METRIMATE 12 way female connector,5mm pitch Pin & Socket Connectors 12 POS RECEPTACLE Conn Housing RCP 12 POS 5mm ST Product Highlights:HousingSquare Grid Connector ConfigurationNumber of Positions = 12ReceptacleWithout Coaxial SocketSearch Keywords:Power Pin & Socket, Soft Shell, NIC, Network Interface Cards, PC Cards, cabled power, wire to board, wire to panel. wire to wire, IEC 440 V, power, pcb connectors, discrete wire, crimp, HOUSING, RECEPTACLE, 12WAY, 5 Connector,SoftShell;Receptacle;12;14A(Max.);600;Thermoplastic;Red Crimp housing 5 mm Poles 12 Contact DesignMale Metrimate, 207018-1, TE Connectivity TE Connectivity Metrimate 系列 4 行 5mm 节距 12 路 直 母 压接连接器外壳 METRIC RCPT 12 POS |
| Category |
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 375 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | IEC |
| Tariff No | 85369010 | Leadfree Defin | Not relevant for lead free process |
| Approval Agency | CSA,UL,VDE | RoHSELV Compliance | RoHS compliant / ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage | 600.0 | Voltage Rating | 600 V |
| Current Rating (Max) | 14 A | Voltage - Supply (Min) | 600VAC |
Mechanical
| Color | Red | Depth | 33.02mm |
| Pitch | 5 mm | Height | 23.8 mm |
| Length | 23.8mm | Weight | 0.004 |
| Packaging | Bulk | Row Spacing | 0.197" (5.00mm) |
| Contact Type | Male Pin | Polarization | PolarizingTab |
| 2nd Connector | With | Housing Color | Red |
| Mounting Type | Straight | Angle of Throw | Straight |
| Connector Type | Housing | Fastening Type | Latch Lock |
| Mounting Style | Panel | Number of Rows | 4 |
| Shaft Diameter | Without | Connector Usage | Square Grid |
| Locking Feature | Locking Tab | Housing Material | Thermoplastic - GF |
| Length - Overall | 23.8 mm | Mounting Feature | Without |
| Package Quantity | 500 | Primary Material | InterconnectSystem |
| Pin Hole Diameter | 0.197" | 1st Contact Gender | Socket (Female) |
| Connector - Sensor | Without | Mating Orientation | Polarizing Tab |
| Number of Contacts | 12 | Contact Termination | Crimp and Solder |
| Number of Positions | 12 | Center Contact Finish | 5.0 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | AMP Metrimate |
| Coded, Keyed | No | Manufacturer | AMP |
| Product Type | Housing | Configuration | SquareGrid |
| Other Specifications | No | For Use With/Related Products | Square Grid Pin & Socket Connector |
Environmental
| Operating Temperature | -55C to 130C | ||
Documents & Media
