205838-1

Business

Lead Time	28 Days	Tradename	CPC Series 2
Subcategory	Connector Circular	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Compliance	No	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Number of Channels	8	Current Rating (Max)	7.5A
Connector - Voltage Input	w/o terminals

Color	Black	Sealed	No
Weight	0.004	Diameter	24.77 mm
Packaging	Bulk	Cable Exit	No
Shell Size	11	Orientation	Keyed
Shell Style	Plug	Termination	Crimp
Thread Size	5/8 - 24 UNEF-2A	Contact Form	8Signal
Contact Size	20	Contact Type	Crimp
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Plug for Female Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Package / Case	size 11	Connector Style	Plug
Insertion Angle	:11-8	Locking Feature	threaded joint, internal thread
Material - Body	:Glass Filled Thermoplastic	Housing Material	Thermoplastic
Length - Overall	20.32 mm	Package Quantity	1
Primary Material	CircularPlasticConnector	Connector - Cable	plug
Termination Style	Wire	1st Contact Gender	Female
Color - Connectors	:Black	Mating Orientation	Keyed
Number of Contacts	8	Contact Tail Length	20D
Insulation Diameter	1.73 [0.068]	Number of Positions	8
Shell Size - Insert	All Plastic	Shell Material, Finish	Thermoplastic
1st Connector Mounting Type	:Cable	2nd Connector Mounting Feature	Standard
Shell Size - Insert (Convert To)	11-8

Spg	1	Note	Contacts Not Provided
Type	CPC	Gender	PL
Series	Series 2	Preloaded	No
Arrangement	11-8	Manufacturer	Series2
Product Type	Connector	Adapter Series	CPC Series 2
Number of Units	1	RF Family/Standard	205838
Other Specifications	Without	Application Specifics	Commercial
For Use With/Related Products	Socket Contacts
