1658658-1

Business

Product Category	D-Sub Standard Connectors	Standard Package	Bulk
Factory Pack Quantity	100

RoHS	RoHS Compliant	Standards	UL94V-0
Tariff No	85369010

Voltage Rating

250VAC

Color	Black	Height	16 mm
Weight	0.01	Packaging	Bulk
Shell Size	3	Wire Gauge	20
Termination	Crimp	Contact Type	Signal
Housing Color	Black	Mounting Type	Straight
Shell Plating	Tin over Copper	Angle of Throw	Straight
Connector Type	Receptacle for Female Contacts	Flange Feature	Cable Side (4-40)
Mounting Style	Wire	Number of Rows	2
Plating - Body	:Tin	Shell Material	Steel
Connector Style	D-Sub	Insert Material	Thermoplastic
Material - Body	:Metal	Shield Material	Steel
Housing Material	Nylon	Length - Overall	56.13 mm
Primary Material	D-Subminiature	Termination Style	Crimp
Number of Contacts	25	Dielectric Material	Polyamide (PA), Nylon, Glass Filled
Number of Positions	25	Shell Size - Insert	:3
Shell Finish Thickness	200µin (5.08µm)	Shell Material, Finish	Steel, Tin Plated
Shell Size, Connector Layout	3 (DB, B)

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Series	HDP-20
Features	Backshell, Shielded	Manufacturer	HDP-20
For Use With/Related Products	:HDP-20 Series D Sub Connectors
