207464-2
| Manufacturer | |
| Description | Conn Housing PL 25 POS Crimp ST D-Sub Standard Connectors 25P PLUG TIN IN Standard Cable Connectors CONN D-SUB HOUSING PLUG 25POS AMPLIMITE HDP-20 d-sub cable plug,25 pin Conn Housing PL 25 POS Crimp ST Product Highlights:ConnectorProduct Series = HDP-20 (Crimp Snap)Number of Positions = 25PlugWithout ContactsSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub PLUG HOUSING, D, T&D, 25WAY Conn;D-Sub;CablePlug;25Pos;STR;HDP-20Series;CrimpSnap;20AWG;MetalShell TE Connectivity AMPLIMITE HDP-20系列 25路 直 压接式 D-sub 连接器, 插头 CRIMP SNAP PLUG ASSY,SZ 3 |
| Category |
Business
| Product Category | D-Sub Standard Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 800 | ||
Compliance
| RoHS | RoHS Compliant | Standards | Insert,UL94V-0 |
| Tariff No | 85369010 | Leadfree Defin | Not relevant for lead free process |
| Approval Agency | ULRecognized,ULListedandCSACertified | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 VAC | Voltage - Working | :250V |
| Contact Resistance | :15mohm | Voltage - Breakdown | :1kV |
| Current Rating (Max) | 3.7/ContactA | Voltage - Supply (Min) | 250VAC |
Mechanical
| Color | Black | Depth | 17.8mm |
| Width | 12.54mm | Height | 12.54 mm |
| Length | 53.03mm | Weight | 0.008 |
| Packaging | Bulk | Shell Size | 3 |
| Wire Gauge | 20 | Termination | Crimp |
| Contact Size | 20 | Contact Type | Signal |
| 2nd Connector | With | Housing Color | Black |
| Mounting Type | Straight | Shell Plating | Tin |
| Angle of Throw | Straight | Connector Type | Crimp Snap |
| Contact Finish | Tin | Flange Feature | Housing/Shell (Unthreaded) |
| Housing Finish | Tin | Mounting Style | Wire |
| Number of Rows | 2 | Plating - Body | :Tin |
| Shell Material | Steel | Connector Style | D-Sub |
| Insert Material | Thermoplastic | Locking Feature | Mounting Holes |
| Material - Body | :Steel | Contact Material | Steel |
| Housing Material | Steel | Length - Overall | 53.03 mm |
| Primary Material | D-Subminiature | Grounding Indents | With |
| Termination Style | Crimp | Number of Contacts | 25 |
| Dielectric Material | Polyamide (PA), Nylon, Glass Filled | Number of Positions | 25 |
| Shell Size - Insert | Full Metal Shell | Shell Material, Finish | Steel, Tin Plated |
| Material - Housing & Prism | :Steel, tin plating | Shell Size, Connector Layout | 3 (DB, B) |
Product Info
| Note | Plugs accept size 20 DF pin contacts. | Type | Housing |
| Grade | Standard | Gender | PL |
| Series | HDP-20 | Features | Grounding Indents |
| Manufacturer | HDP-20 | Product Type | Connector |
| Application Specifics | Commercial | For Use With/Related Products | :HDP-20 Series D Sub Connectors |
Environmental
| Operating Temperature | 105°C | ||
