1658624-1
| Manufacturer | |
| Description | Conn IDC Connector F 10 POS 2.54mm IDT RA Cable Mount Ribbon Cable Connectors (AMP-LATCH) CONN RCPT 10POS POLAR GOLD Headers & Wire Housings 10P RCPT NOVO DUAL Conn IDC Connector F 10 POS 2.54mm IDT RA Cable Mount Product Highlights:With ContactsConnector Type = NOVOHousing Gender = Receptacle10 PositionsReceptacleSearch Keywords:input/output, paddleboard, paddle board 10 NOVO DUAL 30DP, LEAD FREE |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | Rail / Tube |
| Factory Pack Quantity | 900 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR 7189 | Standard Number | CSA, UL |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage Rating | 250 | Voltage - Supply | 250 |
| Resistance - Input | 5000 | Connector Impedance | 刺破式压接 (IDC) |
| Current Rating (Max) | 1 | Connector - Voltage Input | 音叉 |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Width | 7.49 mm [ .2949 in ] | Height | 15.16 mm [ .5968 in ] |
| Length | 17.27 mm [ .6799 in ] | Base Type | 不带 |
| Packaging | Tube | Wire Type | Ribbon Cable |
| Body Color | 黑色 | Cable Exit | Without |
| Cable Type | 带状电缆 | Row Spacing | 0.100" (2.54mm) |
| Termination | IDT | Contact Type | Forked |
| Polarization | Dual Polarizing Bar | 2nd Connector | Without |
| Housing Color | Black | Mounting Type | No |
| Cable End Type | Without | Connector Type | NOVO |
| Contact Finish | Gold Over Palladium Nickel Over Nickel|Gold Over Nickel | Flange Feature | 否 |
| Mounting Style | Cable | Number of Rows | 2 |
| Actuation Force | 不带 | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Housing Material | Thermoplastic |
| Mounting Feature | Without | Package Quantity | 50 |
| Panel Mount Type | 通孔 - 焊接 | Size / Dimension | .08 – .15 mm², 158 – 296 CMA, 28 – 26 美国线规 |
| Cable Termination | IDC | Termination Style | IDC |
| 1st Connector Type | 插针接头 | Mating Orientation | With |
| Number of Contacts | 10 | Insulation Material | .787 – .94 mm [ .031 – .037 in ] |
| Number of Positions | 10 | Contact Length - Post | 信号（数据） |
| Mounting Hole Diameter | 带有 | Contact Finish - Mating | 锡 |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Note | Receptacle can be used in applications requiring non-polarization, as well as m | Type | IDC Connector |
| Gender | F | Features | Feed Through, Polarizing Key |
| Polarity | 带有 | Product Type | Receptacles / Sockets - Housings |
| Connection Type | Ribbon Cable | With Modem Control | Yes |
| DigiKey Programmable | 不带 | Application Specifics | Wire-to-Board |
Environmental
| Operating Temperature | -65 – 105 °C [ -85 – 221 °F ] | ||
