1-1634689-0
| Manufacturer | |
| Description | Conn Shrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Pin and Pinless Headers (AMP-LATCH) CONN HEADER PIN R/A 10POS GOLD TE Connectivity 1-1634689 Series 2.54mm Pitch 10 Way 2 Row Right Angle PCB Header, Solder Termination Headers & Wire Housings HDR R/A 10P Conn Shrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Product Highlights:Connector Type = Pin HeaderLow ProfileNumber of Positions = 102.54 x 2.54 mm Centerline, MatrixPCB Mount Angle = Right AngleSearch Keywords:ribbon cable connector system, input/output, LATCH Universal Header, HEADER, THT, RIGHT ANGLE, 2.54MM, 10WAY Right-angledIDCboxedheader,10-way Socket; IDC; male; PIN:10; angled 90°; THT; gold plated; 2.54mm |
| Category |
Business
| Tradename | AMP-LATCH | Product Category | Headers & Wire Housings |
| Standard Package | Trays | Factory Pack Quantity | 320 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Approval Agency | :UL | Material Flammability Rating | UL 94 V-0 |
Electrical
| Range deg/s | :TE - AMP-LATCH Series | Current Rating (Max) | 1 A |
| Insulation Resistance | 5000 MOhms | ||
Mechanical
| Color | Black | Depth | 12.49 mm |
| Pitch | 2.54 mm | Height | 9.22 mm |
| Weight | 0.0171 | Packaging | Tray |
| Orientation | angled 90° | Row Spacing | 0.100" (2.54mm) |
| Termination | Solder | Contact Type | Male Pin |
| Pitch - Post | 2.54mm | Housing Color | Black |
| Mounting Type | Through Hole, Right Angle | Connector Type | Header, Shrouded |
| Contact Finish | Gold Over Nickel | Mounting Style | Through Hole |
| Number of Rows | 2 | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 20.32 mm |
| Package Quantity | 1 | Primary Material | PCB |
| Connector - Cable | socket | Termination Style | Through Hole |
| 1st Contact Gender | Pin (Male) | Color - Connectors | :Black |
| Number of Contacts | 10 | Contact Termination | :Through Hole Right Angle |
| Number of Positions | 10 | Material - Insulation | :Polyester |
| Contact Length - Mating | 0.228" (5.80mm) | Termination Post Length | 3.02 mm |
| Contact Finish Thickness | 10µin (0.25µm) | Contact Material - Plating | gold plated |
| 1st Connector Mounting Feature | 2x5 | ||
Product Info
| Spg | 1 | Type | Shrouded Header |
| Gender | HDR | Series | 1-1634689 |
| Features | Polarized | Manufacturer | 1634689Series |
| Product Type | Headers | Number of Units | 1 |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | - 40 C to + 105 C | ||
