Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Leadfree Defin | Reflow solder capable to 245°C, Reflow solder capable to 260°C |
| RoHSELV Compliance | Not ELV/RoHS compliant | Material Flammability Rating | UL 94V-0 |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Packaging | Tray | Termination | Solder |
| Contact Type | Male Pin | Pitch - Post | 2.54 [.100] |
| 1st Connector | No | 2nd Connector | Without |
| Contact Shape | Square | Mounting Type | Vertical |
| Connector Type | Breakaway | Contact Finish | Gold Over Nickel |
| Number of Rows | 1 | Contact Material | Phosphor Bronze |
| Housing Material | Liquid Crystal Polymer (LCP) | Mounting Feature | Without |
| Panel Mount Type | Without | Size / Dimension | 0.64 [.025] |
| Number of Contacts | 5 | Number of Positions | 5 |
| Contact Length - Mating | 5.84 [0.230] | Surface Mount Land Size | Yes |
| Termination Post Length | 3.05 [0.120] | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | Unshrouded Header | Gender | HDR |
| Manufacturer | AMP | Product Type | Header |
| Selectively Loaded | No | Number of Positions Loaded | All |
Environmental
| Temperature | Yes | ||
