103648-4
| Manufacturer | |
| Description | Conn Housing RCP 5 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 5POS .100 UNLOADED Headers & Wire Housings 05 MTE RCPT HSG SR R Conn Housing RCP 5 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = Crimp, Insulation Displacement Crimp (IDC)Number of Positions = 5Housing Type = ReceptacleNumber of Rows = SingleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE AMPMODU05MTERCPTHSGSRRIB.100CL TE Connectivity AMPMODU MTE 系列 5路 2.54mm节距 母 IDC 连接器 , 电缆安装 05 MTE RCPT HSG SR RIB .100CL |
| Category |
Business
| Tradename | AMPMODU | Other Names | 1036484 |
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage - Supply | 250 VAC | Connector Impedance | 刺破式压接 (IDC), 压接 |
| Current Rating (Max) | 3 A | Voltage - Protection Rating (VPR) | 600 VACrms |
Mechanical
| Color | Black | Depth | 15.24 mm |
| Pitch | 2.54 mm | Height | 3.5 mm |
| Length | 12.64 mm [ .5 in ] | Lock Type | 不带 |
| Packaging | Bulk | Body Color | 黑色 |
| Wire Gauge | 22-30 AWG | Orientation | 直 |
| Row Spacing | 2.54 mm | Contact Type | Female Socket |
| Polarization | Ribbed | 2nd Connector | Without |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Crimp, Insulation Displacement Crimp (IDC) | Mounting Style | Wire |
| Number of Rows | 1 | Package / Case | Receptacle |
| Insert Material | 磷青铜 | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 12.64 mm |
| Package Quantity | 1 | Termination Rows | 压接 |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Mating Orientation | With | Number of Contacts | 5 |
| Contact Termination | Crimp | Number of Positions | 5 |
| Compatible Shell Size | 公端 | Mounting Hole Diameter | 带有 |
| Center Contact Material | 2.54 [.100] | Contact Layout, Typical | 同轴 |
Product Info
| Note | Refer to AMPMODU contacts for crimp snap-in replacement receptacle or pin conta | Type | Housing |
| Gender | RCP | Series | MTE |
| Preloaded | No | Coded, Keyed | No |
| Product Type | Housing | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | -65C to 105C |
