Product Category	DIN 41612 Connectors	Standard Package	Bulk
Factory Pack Quantity	150

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Reflow solder capable to 245Â°C, Reflow solder capable to 260Â°C	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Size	Standard	Color	Gray
Depth	17.73 mm	Pitch	2.54 mm
Height	11.1 mm	Weight	0.00001
Coating	Without	Packaging	Bulk
Termination	Solder	Contact Size	0.64 [.025] Sq.
Contact Type	Solder Post	Housing Color	Gray
Length - Tail	2.64 mm	Mounting Type	Through Hole
Connector Type	Plug, Male Pins	Contact Finish	Tin
Mounting Style	Through Hole	Number of Rows	3
Contact Material	Copper Alloy	Housing Material	Polymer
Length - Overall	94 mm	Mounting Feature	Without
Make Before Break	No	Termination Style	Solder Pin
Number of Contacts	96	Contact Termination	:Through Hole Right Angle
Number of Positions	96	Material - Insulation	Polymer Thermoplastic, Glass Filled
Termination Post Length	2.65 [0.104]

Type	DIN 41612	Grade	II
Style	C	Gender	Plug
Series	5536010	Features	:Type C
Guide Method	Without	Product Type	Type C Connectors
Bus Connection	FUTUREBUS, MULTIBUS (II), NUBUS, VMEbus, VXIBus	Connection Type	Printed Circuit Board
Tool Type Feature	No	Number of Positions Loaded	All

Temperature	Yes	Level, Class	2
Operating Temperature	-55°C ~ 125°C

5536010-5
