| Product | Jacks | Product Category | DC Power Connectors |
| Standard Package | 1 | Factory Pack Quantity | 100 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85369010 |
Electrical
| Voltage Rating | 12VDC | Number of Poles | 3 |
| Contact Resistance | 0.01Ohms(Max.)(Initial) | Current Rating (Max) | 5A |
| Insulation Resistance | 10000 MOhms | Voltage - Input (Min) | 12VDC |
| Voltage - Supply (Min) | 12VDC | Voltage - Switching DC | 500VAC(Max.) |
Mechanical
| Color | Silver | Pitch | 3.3 mm |
| Length | 0.319in.(Bushing) | Weight | 0.001 |
| Diameter | 10.92 mm | Shielding | Unshielded |
| AC Outlets | :1 | Termination | Solder |
| Contact Type | Pin | Pin Diameter | 0.080in. |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Jack | Mounting Style | PCB |
| Contact Material | Copper Alloy | Housing Material | Plastic |
| Primary Material | Power | Number of Contacts | 3 |
| Contact Termination | :Solder | Contact Finish Thickness | 2.1 mm |
| Plug/Mating Plug Diameter | 2.1mm ID, 5.5mm OD | Contact Material - Plating | Silver |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | Power | Grade | Instrumentation |
| Gender | PL | Series | Right Angle DC Locking Power Jacks |
| Features | Mounting Hardware, Thread Lock | Manufacturer | RASeries |
| Number of Ports | 1 | Internal Switch(s) | Single Switch, Normally Closed |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts | ||
