Business
| Product | Jacks | Other Names | SC1394 |
| Product Category | DC Power Connectors | Standard Package | 100 |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85366990 |
Electrical
| Voltage Rating | 12VDC | Current Rating (Max) | 5A |
Mechanical
| Color | Silver | Weight | 0.001 |
| Packaging | Bulk | Shielding | Unshielded |
| Termination | Solder | Housing Color | Black |
| Mounting Type | Through Hole | Connector Type | Jack |
| Mounting Style | Through Hole | Contact Material | Copper Alloy |
| Housing Material | Thermoplastic | Termination Style | Solder |
| Number of Contacts | 3 | Contact Termination | :Through Hole Right Angle |
| Contact Finish Thickness | 2.5 mm | Plug/Mating Plug Diameter | 2.5mm ID, 5.5mm OD |
| Contact Material - Plating | Nickel | 1st Connector Mounting Type | :PCB |
Product Info
| Type | Power | Gender | F |
| Series | Sealed Power Jacks | Features | IP68, Mounting Hardware, Thread Lock |
| Number of Ports | 1 | Internal Switch(s) | Single Switch, Normally Closed |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts | ||
Environmental
| NEMA Frame Size | :IP68 | ||
