SM6T33A
| Manufacturer | |
| Description | Diode TVS Single Uni-Dir 28.2V 600W 2-Pin SMB T/R TRANSIL UNI 0,6KW 33V SMB TVS DIODE 28.2VWM 59VC SMB TVS Diode Uni-Directional SM6T33A 59V, 600W, SMB 2-Pin TVS Diodes - Transient Voltage Suppressors 600W 33V Unidirect DIODE, TVS, 33V, 600W, SMB DIODE, TVS, 33V, 600W, UNI, SMB, RL SM6T33A TVS diode, 28.2 V 600 W SMB, SM6T33A, ST STMicroelectronics 单向 TVS 二极管, 600W, 59V, 2针 SMB封装 |
| Category |
Business
| MOQ | 2500 | Unit Pack | 2500 |
| Other Names | 497-6493-1 | Product Category | TVS Diodes - Transient Voltage Suppressors |
| Standard Package | Cut Tape, Tape & Reel | Factory Pack Quantity | 2500 |
| Standard Package Name | DO-214-AA | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Automotive | NO | ESD Protection | No |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Channels | 1 Channel | Tolerance | 5% |
| Capacitance | 1000 pF | TVS Polarity | :Unidirectional |
| Current - Surge | 13.1 A | Current - Output | 1 mA |
| Voltage - Supply | 28.2V | Number of Elements | 1 |
| Power - Peak Pulse | 600 W | Voltage - Clamping | 59 V |
| Capacitance @ Vr, F | :1000pF | Diode Configuration | :SMB |
| Voltage - Breakdown | 31.4 V | Voltage - Breakover | :31.4V |
| Voltage - Isolation | :28.2V | Current Rating (Max) | :1mA |
| Contact Voltage (Max) | 28.2V | Power Line Protection | No |
| Voltage - Input (Min) | 28.2 V | Bidirectional Channels | :Undirectional |
| Voltage - Supply (Min) | 28.2 V | Power Dissipation (Max) | 0.6kW |
| Unidirectional Channels | 1 | Current - Peak Pulse (8/20us) | 68 A |
| Current - Reverse Leakage @ Vr | 0.2 uA | Voltage - DC Reverse (Vr) (Max) | :28.2V |
| Current - Peak Pulse (10/1000us) | 68A (8/20µs) | ||
Mechanical
| Width | 3.95(Max) | Weight | 0.00012 |
| Packaging | Tape and Reel | Lead Style | J-Lead |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | 2SMB | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 4.6(Max) | Package Quantity | SMB |
| Size / Dimension | 3.95(Max) mm W x 4.6(Max) mm L | Termination Style | SMD/SMT |
| Number of Positions | 2 | Shell Size - Insert | 2.45(Max) |
| Supplier Device Package | SMB | ||
Product Info
| Type | Zener | Series | SM6T |
| Polarity | Unidirectional | Matchcode | SM6T33A (ET) |
| Diode Type | :Unidirectional TVS | SMD Marking | :ET |
| Applications | General Purpose | Configuration | Single |
| Port Direction | Uni-Directional | Standard Leadtime | 16 weeks |
| Application Specifics | UNIDIRECTI | Printed Circuit Board | 2 |
Environmental
| Operating Temperature | -55 to 150 °C | Operating Temperature - Junction | -55 to 150 |
