点击放大查看
15-24-6146
| Manufacturer | |
| Description | Headers & Wire Housings HEADER 94V-2 538-15-24-6046 CONN HEADER 14POS 4.2MM VERT TIN Conn Power HDR 14 POS 4.2mm Solder ST Thru-Hole 14 Terminal 1 Port Tray |
Business
| Standard Package | 10 | ||
Mechanical
| Color | Natural | Pitch | 0.165" (4.20mm) |
| Packaging | Tray | Row Spacing | 0.165" (4.20mm) |
| Termination | Solder | Contact Type | Male Pin |
| Mounting Type | Through Hole | Connector Type | Header, Shrouded |
| Contact Finish | Tin | Number of Rows | 2 |
| Number of Positions | 14 | Contact Finish Thickness | 100µin (2.54µm) |
Product Info
| Features | Board Lock | Number of Positions Loaded | All |
Documents & Media
Similar Parts
0015248152
molex
Conn Wire to Board HDR 14 POS 4.2mm Solder ST Thru-Hole Tray CONN RCPT 14POS VERT DUAL
0039012140
molex
Conn Housing RCP 14 POS 4.2mm Crimp ST Bag CONN RECEPT 14POS DUAL CONNECTOR HOUSING, RECEPTACLE, 14POS, 2ROW, 4.2MM
0039012145
molex
Conn Housing RCP 14 POS 4.2mm Crimp ST Bag CONN RECEPT 14POS DUAL Conn Housing F 14 POS 4.2mm Crimp ST Cable Mount Bag
76650-0158
molex
COMPONENT KITS, BOARD TO BOARD AND WIRE TO BOARD AND WIRE TO WIRE KIT 10,14,18,4,6,8POS 6A THROUGH HOLE MOUNTING ASSORTED VERTICAL, PLUGS,RECEPTACLE,RIGHT ANGLE HEADER 4.2MM PITCH 600V 24-18 WIRE SIZE KIT MINI-FIT BMI PLUG & RECEPT Board to Board & Mezzanine Connectors MINI-FIT BMI KIT COMPONENT KITS, BOARD TO BOARD AND WIRE TO BOARD AND WIRE TO WIRE KIT 10,14,18,4,6,8POS 6A THROUGH HOLE MOUNTING ASSORTED ... Kit Description:Blind Mate Vertical and Right Angle Header, Vertical Receptacle Header, Plug and ReceptacleKit Category:Wire to Wire and Wire to Board and Board to BoardSolution:Blind-MatePackaging:Tackle Box: 11" by 7.25"Num. Pieces:253 MINI-FIT BMI CONNECTOR KIT
0015247140
Molex
Conn Power RCP 14 POS 4.2mm Solder ST Thru-Hole 14 Terminal 1 Port Tray CONN HEADER 14POS 4.2MM VERT TIN
0424741441
Molex
Conn Housing RCP 14 POS 4.2mm Crimp ST Bag MINIFIT JR BMI PMRCPT DLRW V-0
15-24-7141
