0026604040

Category

Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

Lead Time	24 Days	Subcategory	Connector Headers and PCB Receptacles
Standard Package	600

Compliance

RoHS

Lead free / RoHS Compliant

Electrical

Contact Resistance	6 mohm	Current Rating (Max)	7/Contact A
Voltage - Supply (Min)	250V

Mechanical

Color	Natural	Depth	10.01 mm
Pitch	0.156" (3.96mm)	Height	14.73 mm
Packaging	Bag	Termination	Solder
Contact Type	Male Pin	Housing Color	Natural
Mounting Type	Through Hole	Connector Type	Header, Unshrouded
Contact Finish	Tin	Fastening Type	Friction Lock
Mounting Style	Through Hole	Number of Rows	1
Contact Material	Brass	Housing Material	Polyester
Length - Overall	15.7 mm	Number of Contacts	1
Number of Positions	4	Contact Length - Mating	0.450" (11.43mm)
Contact Finish Thickness	60µin (1.52µm)

Product Info

Type	Wire to Board	Gender	HDR
Industry Aliases	26-60-4040, 26604040	Number of Positions Loaded	All

Environmental

Operating Temperature

0C to 75C

Documents & Media

PDF Document

PDF Document

Other Related Documents

PDF Document

Environmental Information

Online Document

PDF Document

PCN Assembly/Origin

PDF Document

Online Document

PDF Document

PDF Document

Product Drawings

PDF Document

Sourcing & traceability

Datasheet: Datasheets

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
