0009482049

Manufacturer	Molex, LLC
Description	Conn Socket Strip RCP 4 POS 3.96mm Solder ST Thru-Hole Tray CONN RCPT BOTTOM 4POS TIN PCB
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Trays

Compliance

RoHS

Lead free / RoHS Compliant

EU RoHS

Compliant

Electrical

Contact Resistance	6	Current Rating (Max)	5/Contact
Voltage - Input (Min)	250VDC\|250VAC

Mechanical

Color	Natural	Depth	11.92
Pitch	3.96 mm	Height	11.4
Packaging	Tray	Termination	Solder
Contact Type	Female Socket	Housing Color	White
Mounting Type	Through Hole	Connector Type	Receptacle, Bottom Entry
Contact Finish	Tin	Fastening Type	Locking Ramp
Number of Rows	1	Contact Material	Phosphor Bronze
Housing Material	Polyester	Length - Overall	15.75
Number of Contacts	4	Number of Positions	4
Contact Finish Thickness	100µin (2.54µm)

Product Info

Type	Socket Strip	Gender	RCP
Number of Positions Loaded	All

Environmental

Ingress Protection

Operating Temperature

-40°C ~ 105°C

Documents & Media

PDF Document

Product Drawings

PDF Document

datasheet
