C016 30G006 200 12
| Manufacturer | |
| Description | Circular DIN Connectors 6+PE FEM RECEPT BLK SOLDER GLD CONTACT CONN FEMALE RCPT 6+PE GOLD BLACK SOCKET, PANEL, SOLDER, AU, 6P+E WAY CIRCULAR CONNECTOR RECEPTACLE 6POS PANEL connector, plastic circ, female panel recept, 6+gnd gold pltd cont, solder term, blk |
| Category |
Business
| Part # Aliases | 81K1498 | Product Category | Circular DIN Connectors |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85389099 | Approval Agency | :CSA, GERMANISCHER LLOYDS, SEV, UL, VDE |
| Approval Agency Marking | UL Recognized/CSA/VDE | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | 250 V | Voltage - Supply | DIN |
| Contact Resistance | :5mohm | Current Rating (Max) | 10 A |
| Insulation Resistance | :10Mohm | ||
Mechanical
| Color | Black | Weight | 0.021 |
| Packaging | Bulk | Wire Gauge | :20AWG |
| Orientation | Keyed | Shell Style | Receptacle |
| Termination | Solder | Weight (g): | 17.60000 |
| Contact Type | Socket | Mounting Type | Panel Mount |
| Release Force | :30N | Angle of Throw | Straight |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Gold |
| Fastening Type | Threaded | Mounting Style | Free Hanging |
| Package / Case | :Panel Plug | Connector Usage | Threaded |
| Insertion Angle | :- | Insertion Force | :15N |
| Material - Body | :Nylon (Polyamide) | Contact Material | :- |
| Housing Material | Polyamide | Primary Material | DIN |
| Termination Style | Solder | 1st Contact Gender | Socket (Female) |
| Color - Connectors | :Black | Number of Contacts | 6 |
| Contact Termination | :Solder | Dielectric Material | Polyamide |
| Number of Positions | 7 | Shell Size - Insert | :- |
| Mounting Hole Diameter | 0.866 " | Shell Material, Finish | Polyamide |
| Contact Layout, Typical | 6 + 1 Ground (PE) | Mounting Panel Thickness | :31mm |
| Exterior Housing Material | :Polyamide 6.6/PA6 | Wire Gauge or Range - mm2 | :0.75mm² |
| 1st Connector Mounting Type | :Panel | Diameter - Outside, Non-Expanded | :12.5mm |
Product Info
| Type | Cable Socket | Gender | :Socket |
| Series | eco mate | Features | Screw Locking |
| Manufacturer | C016 Series | Product Type | Connectors |
| Application Specifics | Commercial | ||
Environmental
| Seal Rating | IP 67 | Mating Cycles | :500 |
| NEMA Frame Size | :IP67 | Ingress Protection | IP 67, IP 65 |
| Operating Temperature | -40°C ~ 125°C | ||
