82020-6006

点击放大查看

82020-6006

Manufacturer
3M Company
Description
Conn IDC Connector SKT 20 POS 1.27mm IDT RA Cable Mount Headers & Wire Housings 20P TRIPLRZD SOCKET WITH STRAIN RELIEF .050" × .100" Tripolarized Wiremount for .025" Pitch Cable CONNECTOR RECEPT W/STRAIN 20POS Socket,WireMount;Tripolarized;20;CopperAlloy;0.5A;0.025in.;30AWG
Category
Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors
对参数有疑问？问 AI 助手

Business

Part # Aliases05400776027 80620098691Product CategoryHeaders & Wire Housings
Standard PackageBulkFactory Pack Quantity100

Compliance

RoHSNoApproval AgencycUL,UL
Material Flammability RatingUL94V-0

Electrical

Current Rating (Max)0.5 AInsulation Resistance1x109Ohms(Max.)@500VDC

Mechanical

ColorGrayPitch1.27 mm
Weight2 lbsPackagingBulk
Wire TypeRibbon CableWire Gauge30
Row Spacing0.100" (2.54mm)TerminationIDT
Contact TypeFemale SocketMounting TypeVertical
Angle of ThrowStraightConnector TypeReceptacle
Contact FinishGold Over NickelMounting StyleFree Hanging
Number of Rows2Terminal StyleMultipleWires
Contact MaterialCopper AlloyHousing MaterialPolyester
Length - Overall0.755"Primary MaterialWiremount
Cable TerminationIDCPin Hole Diameter0.05"
Termination StyleIDC1st Contact GenderSocket (Female)
Number of Contacts20Number of Positions20
Material - InsulationGlassFilledPolyester(PBT)Contact Finish Thickness30µin (0.76µm)

Product Info

TypeIDC ConnectorGenderSKT
Series820FeaturesFeed Through, Strain Relief
Manufacturer820SeriesProduct TypeReceptacles / Sockets - Housings

Environmental

Operating Temperature-55to+105°C
