点击放大查看
744355147
| Manufacturer | |
| Description | 固定インダクタ WE-HCI Inductor 0.47uH 20% 30A INDUCTOR POWER .47UH 30A SMD Inductor SMD high current WE-HCI 0.47uH Fixed Inductors WE-HCI Inductor 0.47uH 20% 30A INDUCTOR, SMD, HIGH CURRENT 0.41UH Wurth WE-HCI 系列 屏蔽 WE-Perm芯材 绕线贴片电感器, 470 nH ±20%, 50A Idc |
| Category |
Business
| Product | High Current Inductors | Other Names | 732-1122-2 |
| Standard Package | 400 | Factory Pack Quantity | 400 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85045095 | ||
Electrical
| Core Type | :Shielded | Tolerance | ±20% |
| Inductance | 470nH | Range deg/s | :WURTH ELEKTRONIK - WE-HCI Series |
| Test Frequency | 100kHz | Inductance Range | :± 20% |
| DC Resistance (DCR) | 0.67 mOhm | Current Rating (Max) | 30A |
| DC Resistance (DCR) (Max) | :670µohm | Frequency - Self Resonant | 100MHz |
| Current - Saturation (Isat) | :50A | Current Saturation - Series | 50A |
| Resistance - Initial (Ri) (Min) | 0.67mΩ | Current - On State (It (RMS)) (Max) | :30A |
Mechanical
| Depth | 12.8mm | Width | 12.8 mm |
| Height | 6.2mm | Length | 13.2mm |
| Weight | 0.004 | Packaging | Tape & Reel (TR) |
| Shielding | Shielded | Shield Type | Yes |
| Core Material | WE-Perm | Mounting Type | Surface Mount |
| Number of Pins | :2 | Package / Case | Non Standard |
| Size / Dimension | 0.504" L x 0.504" W (12.80mm x 12.80mm) | Termination Style | SMD/SMT |
| Dimensions - Overall | :13.2mm x 12.8mm x 6.2mm | Height - Seated (Max) | 0.197" (5.00mm) |
Product Info
| Type | Wirewound | Series | WE-HCI |
Environmental
| Operating Temperature | -40°C ~ 155°C | ||
