9200090000
| Manufacturer | |
| Description | Connector Accessories Cable Lug Red LIR 1.5 M4 V CABLE TERMINAL |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bag | ||
Compliance
| RoHS | Not applicable / Not applicable | Standard Number | 23-17-16-04 |
Electrical
| Frequency | 27-40-02-12 | Minimum Core Cross Section (Amin) mm2 | 0.5 mm² |
Mechanical
| Color | Red | Width | 5.9 mm |
| Length | 22.4 mm | Weight | 0.71 g |
| Packaging | Bulk | Insulation | Insulated |
| Cord Length | 11.3 mm | Termination | Crimp |
| Core Diameter | 4 mm | Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | M4 Stud | Terminal Type | Standard |
| Cable Diameter | 1.5 mm² | Width (Inches) | 0.232 inch |
| Length (Inches) | 0.882 inch | Size / Dimension | M 4 |
| Diameter - Inside | 4.3 mm | Diameter - Outside | 8 mm |
| Width - Outer Edges | 0.315" (8.00mm) | Material - Insulation | Poly-Vinyl Chloride (PVC) |
Product Info
| Type | Cable Lug | ETIM 6*0 | EC001059 |
| GTIN (EAN) | 4032248409853 | Bus Connection | 0.75 mm |
| Firmware Version | cable lug, terminal end,Insulated cable connector,0.5 mm² - 1.5 mm²,Red | RF Family/Standard | 9200090000 |
Environmental
| ET (Volt-Time) | EC000168 | Ingress Protection | 21-04-03-01 |
