Manufacturer	Weidmüller Holding AG & Co. KG
Description	Conn RJ-45 M IDT ST Cable Mount 1 Port Cat 6a CONN MOD PLUG 8P8C SHIELDED
Category	Connector SolutionsModular ConnectorsRJ45 Modular Connectors

Frequency	19-17-01-25	PoE Ports	conforming to IEEE 802.3af
Contact Resistance	≤ 20 mΩ	Dielectric Strength	≥ 1500 V DC
Voltage - Breakdown	≥ 1000 V DC	Current Rating (Max)	1A
Resistance Tolerance	250 ms-2	Insulation Resistance	50 ms-2 sinusoidal (9 – 500 Hz)
Current Rating - Appliance Inlet	1 A

Color	Translucent - Clear	Weight	13.5 g
Packaging	Bulk	Shielding	Shielded
Cable Type	Round Cable, Solid or Stranded Wires	Wire Gauge	24-27 AWG
Termination	IDT	1st Connector	RJ45
Core Diameter	0.4...0.51 mm	Mounting Type	Cable Mount
Cable Diameter	0.46...0.61 mm	Contact Finish	Gold
Contact Material	Phosphor Bronze	Housing Material	Brass, PC UL 94 V0
Color - Connectors	Miscellaneous	Cross Section Shape	AWG 24...AWG 24
Connector/Contact Type	IEC 60603-7-51	Contact Finish Thickness	31.5µin (0.80µm)
1st Connector Orientation	z1755b-07-E.pdf	2nd Connector Mounting Type	IDC

Type	RJ-45	Gender	M
ETIM 6*0	EC001121	GTIN (EAN)	4032248644834
Description	Plug insert RJ45, crimp	Communications	ANSI / TIA / EIA-568-B.2-10, DIN EN 61918 Draft 02.2007, EN 50173-1:2007, ISO / IEC 11801:2002, ISO / IEC 24702:2006
Firmware Version	RJ45 insert, Plug insert RJ45, crimp	Number of Positions/Contacts	8p8c (RJ45, Ethernet)
