TLHO4400

Manufacturer	Vishay Intertechnology, Inc.
Description	LED Uni-Color Orange 605nm 2-Pin T-1 Standard LEDs - Through Hole Orange Tint Diffused LED 3MM ORANGE 13MCD GAASP GAP LED Uni-Color Orange 605nm 2-Pin T-1 T/R LED, ORANGE, T-1 (3MM), 4MCD, 611NM LED, 3MM, ORANGE LED;Red;4mcd;3mmDia.;T-1;30mA;2.4V;605nm;+/-30deg;GaAsPonGaP;15V;100mW Vishay 橙色 (611 nm 主波长) LED, , 3 V, 13 mcd, ±30 °视角 3mm (T-1) 通孔
Category	OptoelectronicsDiscrete LED IndicationHigh Brightness LEDs

对参数有疑问？问 AI 助手

Business

Other Names	751-1120	Product Category	Standard LEDs - Through Hole
Standard Package	Bulk	Factory Pack Quantity	5000
Standard Package Name	T-1

Compliance

RoHS	RoHS Compliant	EU RoHS	Compliant
Tariff No	85366190	Rad Hardened	No

Electrical

Lamp Type	:T-1 (3mm)	Optic Size	T-1
Lamp Output	No	Luminous Flux	13 mcd
Power - Rated	100 W	Viewing Angle	60 °
Current - Output	10mA	Voltage - Supply	2.4V
Wavelength - Peak	605 nm	Number of Elements	1
Current - Trip (It)	10 mA	LED Forward Current	10 mA
LED Forward Voltage	2.4 V	Millicandela Rating	13mcd
Wavelength - Dominant	611(Max)nm	Power Dissipation (Max)	100
Current - Dark (Id) (Max)	:10mA	Voltage - Peak Reverse (Max)	:6V
Current - Peak Pulse (8/20us)	:30mA	Current - DC Forward (If) (Max)	:20mA
Current - Peak Pulse (10/1000us)	30	Voltage - Gate Trigger (Vgt) (Max)	15 V

Mechanical

Color	Orange	Depth	3.2 mm
Shape	Circular	Height	4.50mm
Length	:4.5mm	Weight	0.002
LED Color	:Orange	Packaging	Bulk
Lead Style	Through Hole	Lens Color	Tinted, Diffused
Lens Style	Circular	Light Color	Red Orange
Lead Spacing	:2.54mm	Lens Diameter	2.9 mm x 2.9 mm x 3.5 mm
Mounting Type	Through Hole	Inner Diameter	:0.5mm
Mounting Style	Top Mount	Number of Pins	:2
Optic Material	:Radial Leaded	Package / Case	2T-1
Package Cooled	T-1	Lens Style/Size	Round with Domed Top, 3mm, T-1
Material - Core	GaAsP	Length - Overall	3.2 mm
Package Quantity	T-1	Size / Dimension	:3mm / T-1
Diameter - Outside	:2.9mm	Illumination Color	Orange
Length - Lead Wire	:23mm	Number of Positions	2
Shell Size - Insert	4.5	Diameter - Inside, Expanded	:0.5mm

Product Info

Type	Uni-Color	Lens Type	Colored Diffused
Main Purpose	Standard LED	Number of LEDs	1
Printed Circuit Board	2

Environmental

Operating Temperature

+ 100 C

Luminous Flux @ Current/Temperature

4 mcd

Documents & Media

PDF Document

tlhg440.pdf

PDF Document

6619.pdf
