SN74LVC1G126DCKR
| Manufacturer | |
| Description | Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SC-70 T/R IC BUS BUFF TRI-ST N-INV SC705 Buffers & Line Drivers SINGLE BUS BUFFER GATE IC NON INVERTING BUS BUFFER GATE SC-70-5 LOGIC, 74LVC1G, BUFFER/DRIVER, SC705 Single Bus Buffer Gate With 3-State Outputs Logic IC SC-70-5, SN74LVC1G126, SN74LVC1G126DCKR, Texas Instruments Texas Instruments 74LVC 系列 三态 非反相 缓冲器 SN74LVC1G126DCK, 5针 SC-70封装 |
| Category |
Business
| Other Names | 296-11606-2 | Product Category | Buffers & Line Drivers |
| Standard Package | Cut Tape | Factory Pack Quantity | 3000 |
Compliance
| RoHS | Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85411000 | Part Status | ACTIVE |
| Rad Hardened | No | ||
Electrical
| Voltage | 1.8 2.5 3.3 5 | Tolerance | 5 |
| Input Type | CMOS/TTL | Logic Type | LVC |
| Output Type | 3-State | Input Signal | Single-Ended |
| Number of I/O | 5 V | Number of Bits | 1 |
| Number of Inputs | 1 | Voltage - Supply | 1.65 V ~ 5.5 V |
| Number of Outputs | 1 | Number of Channels | 1 |
| Number of Elements | 1 | Current Rating (Max) | Catalog |
| Frequency - Output 1 | 150 | Schmitt Trigger Input | No |
| Voltage - Input (Min) | 5.5 | Current - Output (Max) | -32 |
| Current - Output (Typ) | 32 | Voltage - Supply (Min) | 1.65 V |
| Propagation Delay (Max) | 9.8 | Current - Quiescent (Iq) | 10 uA |
| Delay Time - Propagation | 4.5 ns at 3.3 V, 4 ns at 5 V | Current - Quiescent (Max) | 0.01 |
| Current - Output High, Low | 32mA, 32mA | Number of Bits per Element | 1 |
| Number of Outputs and Type | 1 | Current - Output Source/Sink | 32/-32 |
| Max Propagation Delay @ V, Max CL | 4.5@3.3V|4@5V ns | Propagation Delay tpLH / tpHL (Max) | 8 5.5 4.5 4 |
Mechanical
| Width | 1.4(Max) | Weight | 0.000088 oz |
| Packaging | Tape and Reel | Termination | :SMD |
| Mounting Type | Surface Mount | Conductor Type | Gull-wing |
| Mounting Style | SMD/SMT | Number of Pins | 5 |
| Package / Case | 5SC-70 | Package Cooled | SOT-323 |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 2.15(Max) |
| Package Quantity | 3000 | LARGE T&R | Packages Included | SC-70 |
| Number of Positions | 5 | Shell Size - Insert | 1(Max) |
| Supplier Device Package | SC-70-5 | ||
Product Info
| Series | SN74LVC1G126 | Function | Buffer/Line Driver |
| Polarity | Non-Inverting | Software | SCES224R |
| Technology | CMOS | Channels per IC | 1 |
| Functional Diagram | fbd_sces224r.gif | RF Family/Standard | LVC |
| Utilized IC / Part | View | Printed Circuit Board | 5 |
| Assembly Configuration | Surface Mount | ||
Environmental
| Temperature - Test | -40 to 125 | Operating Temperature | -40°C ~ 85°C |
