SN74AVC4T245PWT
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 296-29001-1 | Standard Package | Tape & Reel |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Part Status | :74AVC4T245 | ||
Electrical
| Data Rate | 380Mbps | Input Type | Logic |
| Logic Type | AVC | Output Type | 3-State |
| Number of Bits | 4 | Voltage Rating | 1.2 |
| Current - Output | :12mA | Number of Inputs | :4 |
| Voltage - Supply | 1.8|2.5|3.3 V | Propagation Delay | :3.1ns |
| Number of Channels | 4 | Current Rating (Max) | Catalog |
| Frequency - Output 1 | 100 | Schmitt Trigger Input | No |
| Voltage - Supply (Min) | 3.6 | Propagation Delay (Max) | 2.9ns |
| Current - Quiescent (Max) | 0.08 mA | Current - Output High, Low | 12 mA |
| Idle Current, Typ @ 25degC | 0.008 | Number of Outputs and Type | 1 |
| Differential - Input:Output | No/No | Max Propagation Delay @ V, Max CL | 6.3@1.5V ns |
| Propagation Delay tpLH / tpHL (Max) | 3.4 3.2 2.9 2.8 | ||
Mechanical
| Width | 4.5(Max) | Weight | 0.000062 |
| Packaging | Tape and Reel | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Number of Pins | :16 | Package / Case | 16TSSOP |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 5.1(Max) |
| Package Quantity | TSSOP | Number of Positions | 16 |
| Shell Size - Insert | 1.05(Max) | Supplier Device Package | 16-TSSOP |
Product Info
| Process | CMOS | Function | Voltage Level Translator |
| Software | SCES576G | Base Unit | :74 |
| Pattern Number | Y | Functional Diagram | alt_sces576g.gif |
| RF Family/Standard | AVC | Utilized IC / Part | View |
| Printed Circuit Board | 16 | ||
Environmental
| Temperature - Test | -40 to 85 | Operating Temperature | -40°C ~ 85°C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 1767032.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
