CC2591RGVT
| Manufacturer | |
| Description | Analog RF Front End 16-Pin VQFN EP T/R RF Front End 2.4 GHz RF Front End LNA/PA RF Front End 22dB 4.8dB 16-Pin VQFN EP T/R IC RF FRONT END 2.4GHZ 16-QFN LNA/PARF Front End 22dB 4.8dB 16-Pin VQFN EP T/R TRANSCEIVER, RF FE, 2.4GHZ, 16QFN IC, RF FRONT END, 2400-2483.5MHZ, QFN-16 |
| Category |
Business
| Other Names | 296-23603-1 | Product Category | RF Front End |
| Standard Package | Tape & Reel, Cut Tape | Factory Pack Quantity | 250 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| Frequency | 2.4 GHz | Modulation | :- |
| Power Input | -17 | Filter Order | :32dBm |
| Noise Figure | 4.8 dB | Output Power | :22dBm |
| Power - Output | :20.6dBm | Voltage Rating | 2 |
| Frequency - Max | :2.4835GHz | Frequency - Min | :2.4GHz |
| Frequency Range | :2.4GHz to 2.4835GHz | Current - Output | 1.7 mA to 3.4 mA |
| Interrupt Output | 32 | Voltage - Supply | :2V |
| Current - Receiving | :3.4mA | Current - Transmitting | :112mA |
| Voltage - Supply (Min) | 3.6 | Power (Typ) @ Conditions | 22 |
| Noise Figure (dB Typ @ f) | :4.8dB | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 4.15(Max) | Weight | 0.0002 |
| Packaging | Reel | Lead Style | No Lead |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :16 |
| Package / Case | 16VQFN EP | Material Finish | :MSL 2 - 1 year |
| Length - Overall | 4.15(Max) | Package Quantity | VQFN EP |
| Number of Positions | 16 | Shell Size - Insert | 0.95(Max) |
| Supplier Device Package | 16-VQFN (4x4) | ||
Product Info
| Type | 802.15.4, Zigbee | Series | CC2591 |
| RF Type | 802.15.4/ZigBee | Base Unit | :2591 |
| Structure | LNA/PA | Printed Circuit Board | 16 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
