OPA2604AP
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Operational Amplifiers - Op Amps | Standard Package | Rail / Tube |
| Factory Pack Quantity | 50 | Standard Package Name | PDIP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423300 |
| Part Status | :2604 | Rad Hardened | No |
Electrical
| Gain | 100 dB | PSRR | 70 dB |
| Slew Rate | 25@±15V V/us | Vn at 1kHz | 11 |
| Output Type | No | Offset Drift | 8 |
| Power - Input | Dual | Rise Time (Typ) | 25V/μs |
| Transistor Type | :Low Noise | CMRR, PSRR (Typ) | 80 dB |
| Current - Output | 10.5mA | Current - Supply | 12@±15V mA |
| Voltage - Supply | ±4.5 V | Power Supply Type | Dual |
| Number of Channels | 2 | Number of Elements | 2 |
| Current - Input Bias | 100pA | Current Rating (Max) | Catalog |
| Number of ADCs / DACs | :2 | Voltage - Input (Min) | 1mV |
| Gain Bandwidth Product | 20 MHz | Rail-to-Rail Operation | No |
| Current - Quiescent (Iq) | 6 | Current - Input Bias (Max) | 0.0001(Typ)@±15V uA |
| Current - Output / Channel | 35mA | Input Offset Current (Max) | 0.000004(Typ)@±15V |
| Voltage - Supply (Vcc/Vdd) | 48 | Vos (Offset Voltage @ 25C) | 5 |
| Input Noise Current Density | 0.006@±15V pA/rtHz | Input Noise Voltage Density | 25@±15V nV/rtHz |
| Voltage - Supply Span (Typ) | �5/�9/�12/�15 V | Frequency Bands (Low / High) | 20MHz |
| Voltage - Input Offset (Max) | 5@±15V mV | Voltage - Output Difference (Typ) @ Distance | 100 dB |
Mechanical
| Width | 6.6(Max) | Weight | 0.018455 oz |
| Bandwidth | :20MHz | Packaging | Tube |
| Lead Style | Through Hole | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Number of Pins | :8 |
| Package / Case | 8PDIP | Package Cooled | PDIP |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 10.16(Max) |
| Package Quantity | PDIP | Number of Positions | 8 |
| Shell Size - Insert | 5.08(Max) - 0.51(Min) | Supplier Device Package | 8-PDIP |
Product Info
| Spg | 50 | Type | General Purpose Amplifier |
| Series | OPA2604 | Shutdown | No |
| Software | SBOS006 | Base Unit | :2604 |
| Technology | BiFET | Manufacturer | Wideband Amplifier |
| Amplifier Type | General Purpose | Number of Units | 1 |
| Number of Circuits | 2 | Utilized IC / Part | :OPA2604AP. |
| Printed Circuit Board | 8 | ||
Environmental
| Operating Temperature | -25 to 85 °C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 1504675.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
