87733-1
| Manufacturer | |
| Description | Conn Housing RCP 20 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSNG 20POS .100 POL W/STR Headers & Wire Housings RECEPTACLE 20P DUAL Conn Housing RCP 20 POS 2.54mm Crimp ST Cable Mount Product Highlights:HousingNot PreloadedNumber of Positions = 20Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 20 MODIV HSG W/STR RLF DR MRKD |
| Category |
Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 100 |
Compliance
| RoHS | Lead free / RoHS Compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 VAC | Switch Function | Detent Latching |
| Voltage - Supply | 250 VAC | Contact Resistance | 12 mΩ |
| Resistance - Input | 5000 | Connector Impedance | 压接 |
| Current Rating (Max) | 3 A | Voltage - Protection Rating (VPR) | 750 V |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.1 mm [ .24 in ] | Length | 25.4 mm [ 1 in ] |
| Lock Type | 带有 | Packaging | Bulk |
| Body Color | 黑色 | Wire Gauge | 20-32 AWG |
| Row Spacing | 0.100" (2.54mm) | Contact Type | Male or Female |
| Mounting Type | Straight | Connector Type | Receptacle |
| Fastening Type | Locking Ramp | Mounting Style | Wire |
| Number of Rows | 2 | Insert Material | 磷青铜 |
| Housing Material | Thermoplastic | Package Quantity | 100 |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 20 | Contact Termination | Crimp |
| Number of Positions | 20 | Mounting Hole Diameter | 带有 |
| Static Discharge Shielding | 带有 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | AMPMODU MOD IV |
| Features | Strain Relief | Product Type | Receptacles / Sockets - Housings |
| Number of Taps/Steps | 2 | Other Specifications | 是 |
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | - 65 C to + 105 C |
