86566-4
| Manufacturer | |
| Description | Contact SKT Crimp ST Cable Mount Strip Flexible Film Contacts CONN SOCKET 22-26AWG 30GOLD FFC & FPC Connectors FFC RCPT CRIMP S-I 86566-4 Contact SKT Crimp ST Cable Mount Strip Product Highlights:SocketContact Type = ReceptacleWire Range = 0.12-0.40² [26-22] mm [AWG]2.54 mm CenterlineWire/Cable Type = Round Wire, DiscreteSearch Keywords:mass termination, Flexcircuit, flat flexible cable, flat flex wire, FFC RECP CRIMP S-I |
| Category |
Business
| Product Category | FFC & FPC Connectors | Standard Package | Tape & Reel |
| Factory Pack Quantity | 13000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | ||
Electrical
| Connector Impedance | 压接 | ||
Mechanical
| Pitch | 2.54 mm [ .1 in ] | Packaging | Tape & Reel (TR) |
| Cable Type | Round Wire, Discrete | Wire Gauge | 22-26 AWG |
| Termination | Crimp | Contact Type | Signal |
| Pin or Socket | Socket | Connector Type | Connector Headers and PCB Receptacles |
| Contact Finish | Gold Over Nickel | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Length - Overall | 2.54 [0.100] |
| Material - Frame | 镍 | Package Quantity | Strip |
| Termination Style | 插座 | Contact Termination | Crimp |
| Insulation Diameter | 1.02 â 1.42 [0.040 â 0.056] | Contact Finish Thickness | 30µin (0.76µm) |
| Wire Gauge or Range - mm2 | 0.12-0.40² [26-22] | ||
Product Info
| Mfr | 1.27, 1.82 | Note | Crimp Control Monitor 567561-2 for AMP-O-LECTRIC.; Crimp Control Monitor 567561 |
| Gender | SKT | Product Type | Contacts |
Documents & Media
