794954-8

Business

Product Category	Pin & Socket Connectors	Standard Package	Bulk
Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Part Status	E28476	Leadfree Defin	Not relevant for lead free process
CSA File Number	208567	Standard Number	CSA, UL
RoHSELV Compliance	RoHS compliant, ELV compliant	UL Flammability Rating	UL 94V-2
Approval Agency Marking	否	Material Flammability Rating	UL 94V-2

Color	Natural	Depth	20mm
Pitch	4.2 mm	Width	20 mm [ .787 in ]
Height	11.8 mm [ .464 in ]	Length	18.4mm
Sealed	Not Sealed	Weight	2 g
Material	Nylon	Packaging	Bulk
Cable Type	分离式导线	Orientation	直
Row Spacing	0.165" (4.20mm)	Contact Type	Female Socket
Pitch - Post	4.2mm	Housing Color	Natural
Mounting Type	Straight	Connector Type	Receptacle
Contact Finish	Without	Fastening Type	Latch Lock
Mounting Style	Free Hanging	Number of Rows	2
Package / Case	Receptacle	Insertion Force	15
Housing Material	Nylon	Length - Overall	18.4 mm
Package Quantity	1	Connector - Cable	plug
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Number of Contacts	8	Contact Termination	Crimp
Insulation Diameter	1.2 – 3.1 mm [ .047 – .122 in ]	Number of Positions	8
Compatible Shell Size	印刷电路板	Contact Layout, Typical	矩阵
1st Connector Mounting Feature	2x4

Spg	1	Note	Contacts Not Provided
Type	Housing	Gender	RCP
Series	PE	CAD Drawing	3D CAD Model
Product Type	Housing	Adapter Series	VAL-U-LOK
Number of Units	1	Connection Method	Wire-Board
Number of Circuits	8	Selectively Loaded	No
For Use With/Related Products	Wire-to-Board Connector, Wire-to-Panel Connector, Wire-to-Wire Connector
